6.3.3

Rebuilding failed drives

You can manually rebuild failed hard disk drives using the Rebuild command in the
Management Menu.
To rebuild a failed hard disk drive:
From the Management Menu, highlight Rebuild, then press <Enter>.
1.
LSI Software RAID Configuration Utility Ver A.53 Sep 06, 2007
Management Menu
Configure
Initialize
Objects
Rebuild
Check Consistency
Use Cursor Keys to Navigate Between Items And Press Enter To Select An Option
2. The PHYSICAL DRIVES SELECTION MENU displays the available drives
connected to the SATA ports. Select the drive you want to rebuild, then press
<SpaceBar>.
LSI Software RAID Configuration Utility Ver A.53 Sep 06, 2007
Management Menu
Configure
Initialize
Objects
Rebuild
Check Consistency
P o r t # 1 D I S K 1 5 6 4 0 2 M B H D S 7 2 8 0 8 0 P L A 3 8 0
PF20A60A
SPACE-Sel,ENTER-EndArray,F10-Configure,F2-Drive Info,F3-Virtual Drives,F4-HSP
ASUS RS100-E5-PI2
Rebuild PD(s)
REBUILD - PHYSICAL DRIVES SELECTION MENU
PORT #
0
ONLIN A00-01
3
ONLIN A00-00
6-23
