5.4.5 CPU Configuration
The items in this menu show the CPU-related information that the BIOS
automatically detects.
Advanced
Configure advanced CPU settings
Module Version: 3D.06
Manufacturer: Intel
Brand String: Intel(R) Xeon(R) CPU X3230 @ 2.66GHz
Frequency : 2.66GHz
FSB Speed : 1066MHz
Cache L1 : 128 KB
Cache L2 : 8192 KB
Ratio Status: Unlocked (Max:10, Min:06)
Ratio Actual Value
CPUID :6FB
C1E Support
Max CPUID Value Limit:
Vanderpool Technology
CPU TM function:
Execute Disable Bit
v02.58 (C)Copyright 1985-2007, American Megatrends, Inc.
The CPU configuration screen may be not exactly match the information on
your screen, it will change according to your actual CPU type.
C1E Support [Enabled]
Allows you to enable or disable the Enhanced Halt State.
Configuration options: [Disabled] [Enabled]
Max CPUID Value Limit [Disabled]
Enable this item to boot legacy operating systems that cannot support CPUs with
extended CPUID functions.
Configuration options: [Disabled] [Enabled]
Vanderpool Technology [Enabled]
The Vanderpool Technology allows a hardware platform to run multiple operating
systems separately and simultaneously, enabling one system to virtually function
as several systems.
Configuration options: [Disabled] [Enabled]
CPU TM function: [Enabled]
This function enables the overheated CPU to throttle the clock speed to cool down.
Configuration options: [Disabled] [Enabled]
Execute Disable Bit [Enabled]
Allows you to enable or disable the No-Execution Page Protection Technology.
Setting this item to [Disabled] forces the XD feature flag to always return to zero
(0).
Configuration options: [Disabled] [Enabled]
ASUS RS100-E5-PI2
BIOS SETUP UTILITY
:10
[Enabled]
[Disabled]
[Enabled]
[Enabled]
[Enabled]
This should be enabled
in order to enable or
disable the "Enhanced
Halt State".
Select Screen
Select Item
+- Change Option
F1 General Help
F10 S ave and Exit
ESC E xit
5-19
