4.
Select a Main Cooling System BOX cooler, Tower cooler, Water cooler, or I'm not
sure, then click Next.
5.
After selecting the Main Cooling System, click Next then click Yes to start the OC
Tuning.
Creating RAID
To create RAID:
1.
Press <F11> on your keyboard or click
EZ Tuning Wizard screen.
2.
Click RAID then click Next.
•
•
3.
Select the port that you want to set to [RAID] mode, PCIE or SATA, then click Next.
3-10
Ensure that your HDDs have no existing RAID volumes.
Ensure to connect your HDDs to Intel
from the BIOS screen to open
SATA connectors.
®
Chapter 3: BIOS Setup
