* LAN ports LED indications
Activity Link LED
Status
Off
Orange
Orange (Blinking) Data activity
Orange (Blinking
then steady)
** Audio 2, 4, 6, or 8-channel configuration
Headset
Port
2-channel
Light Blue Line In
Lime Line Out
Pink Mic In
Orange –
Black –
2-14
USB 3.1/3.0 devices can only be used as data storage only.
We strongly recommend that you connect your devices to ports with matching data
transfer rate. Please connect your USB 3.0 devices to USB 3.0 ports and your USB
3.1 devices to USB 3.1 ports for faster and better performance for your devices.
All USB devices connected to the USB 2.0 and USB 3.0 ports are controlled by the
xHCI controller. Some legacy USB devices must update their firmware for better
compatibility.
Description Status
No link Off
Linked Orange 100 Mbps connection
Green
Ready to wake up
from S5 mode
4-channel
Line In
Front Speaker Out
Mic In
–
Rear Speaker Out
Speed LED
Description
10 Mbps connection
1 Gbps connection
6-channel
Line In or side
Line In
speaker
Front Speaker Out Front Speaker Out
Mic In Mic In
Center/Subwoofer Center/Subwoofer
Rear Speaker Out Rear Speaker Out
Chapter 2: Basic Installation
ACT/LINK SPEED
LED
LED
LAN port
8-channel
