ORIGINAL OPERATING INSTRUCTIONS
PM 4-M multi-line laser
It is essential that the operating instructions
are read before the tool is operated for the
en
first time.
Always keep these operating instructions to-
gether with the tool.
Ensure that the operating instructions are
with the tool when it is given to other persons.
Contents
1 General information
2 Description
3 Accessories
4 Technical data
5 Safety instructions
6 Before use
7 Operation
8 Care and maintenance
9 Troubleshooting
10 Disposal
11 Manufacturer's warranty - tools
12 FCC statement (applicable in USA)
13 EC declaration of conformity (original)

1 General information

1.1 Safety notices and their meaning
DANGER
Draws attention to imminent danger that will lead to
serious bodily injury or fatality.
WARNING
Draws attention to a potentially dangerous situation that
could lead to serious personal injury or fatality.
CAUTION
Draws attention to a potentially dangerous situation that
could lead to slight personal injury or damage to the
equipment or other property.
NOTE
Draws attention to an instruction or other useful informa-
tion.
12
1 These numbers refer to the corresponding illustra-
tions. The illustrations can be found on the fold-out cover
pages. Keep these pages open while studying the oper-
ating instructions.
In these operating instructions, the designation "the tool"
always refers to the PM 4-M multi-line laser.
Parts, operating controls and indicators 1
On/off button with LED
@
Rotary knob for pendulum locking mechanism
;
Laser exit window
Page
=
Fine adjustment for rotation platform
12
%
Adjustable foot
13
&
Circular bubble level
14
(
Battery compartment
14
)
15
16
17
19
19
20
20
21
21
1.2 Explanation of the pictograms and other
information
Warning signs
General
warning
Symbols
Read the
operating
instructions
before use.
and batteries
together with
Disposal of
power tools
or
appliances
household
waste is not
permissible.
