Midas XL42 Operator's Manual page 26

Metering
Type
Equaliser
Hi pass slope
Hi pass frequency
Treble Gain
Treble Shelving Freq.
Hi Mid Gain
Hi Mid Freq.
Hi Mid Bandwidth
Lo Mid Gain
Lo Mid Freq.
Lo Mid Bandwidth
Bass Gain
Bass Shelving Freq.
Bass Bell Freq.
Bass Bell Bandwidth
Automute System
Channel Quantity
Mute ON Voltage
Mute Off Voltage
Mute Line Load
Power
Nominal Mains Voltage
Mains Consumption
Phantom Voltage Supply
Maximum Phantom Current
Dimensions
Width
Depth
Height
Weight
Nett
Shipping
Options
Mic Transformer
Output Transformer
Technical Specification Technical Specification
10 Segment LED Bargraph - Peak Reading
12dB/Oct
Continuously variable -3dB point from 10Hz to 400Hz
Continuously variable +15dB to -15dB
Centre detent = 0dB
Continuously variable - 3dB point from 1k to 20k
Continuously variable +15dB to -15dB
Centre detent = 0dB
Continuously variable centre from 400Hz to 8k
Continuously variable 0.1 Oct. to 2 Oct.
Continuously variable +15dB to -15dB
Centre detent = 0dB
Continuously variable centre from 100Hz to 2k
Continuously variable 0.1 Oct. to 2 Oct
Centre detent = 0.5 Oct
Continuously variable +15dB to -15dB
Centre detent = 0dB
Continuously variable - 3dB point from 20Hz to 400Hz
Continuously variable centre from 20Hz to 400Hz
Continuously variable 0.1 Oct. to 2 Oct
Centre detent = 0.5 Oct
8
+3 to +20V
-20 to +2V
>500kOhm
115V/230V
40W
+48V ± 5%
<10mA
482mm (19 inches)
250mm (10 inches)
44mm (1.75 inches)
3kg
4kg
Factory-Fit Only
Factory-Fit or Retrofit
XL42 Operators Manual - Page 18
