Rear Panel - Midas XL42 Operator's Manual

Left / Right Input
Left / Right Link Input
Left / Right Output
Left / Right Insertion
Points
Remote Control
Automute Assigns
Automute Input /
Automute Link
Supply Voltage
IEC Power Inlet
Your XL42 should come complete with the correct IEC mains lead for
the country in which it was intended for sale. If replacing the mains
lead, replace with a recommended part and ensure that the fuse is
of the correct type.
The XL42 must be earthed.
XL42 Operators Manual - Page 9
The XL42 rear panel houses both the input and output
sockets as well as the insert points, remote control and
Automute sockets and power inlet and selector.

Rear Panel

Rear Panel
