EQ section

The Bass, Lo-Mid, Hi-Mid and Treble bands use dual concentric rotary controls. The outside ring controls the band cut
and boost in the range -15dB to +15dB. The inner ring of the dial controls the bandwidth of the filter in the range 0.1 to
2 octaves (with a centre detent at 0.5 octave).
Bass Band Gain/Attenuation
( o u t s i d e
bandwidth
activated when Bell 9 - is
selected).
The Lo-Cut control selects
the HPF frequency and is
continuously variable from
20Hz to 400Hz. The Lo-Cut
filter is enabled by pressing
the Lo-Cut switch.
The Lo-Cut Switch is a
conventional latching switch
where the filter is enabled
w h e n t h e s w i t c h i s
depressed.
T h e B a s s
control selects the frequency
at which the bass equaliser
b a n d a c t s
continuously variable from
20Hz to 400Hz.
L o - M i d
r i n g ) . B a s s Gain/Attenuation
ring).
(inside ring
(inside ring).
The Lo-Mid FREQUENCY
control selects the frequency
at which the lo-mid equaliser
b a n d a c t s a n d
continuously variable from
100Hz to 2KHz.
The EQ Switch enables or
disables the equaliser in the
signal path. (This parameter
is automatable).
F R E Q U E N C Y
a n d i s
The Bass Band BELL switch
enables or disables the
Parametric EQ for the bass
band. The Bell switch is a
conventional latching switch
- when depressed the
equaliser band will work in
f u l l p a r a m e t r i c m o d e ,
otherwise the equaliser band
will act like a traditional
MIDAS shelving response
EQ.
XL42 Operators Manual - Page 7
B a n d
(outside
Lo-Mid bandwidth
H i - M i d B a n d
Gain/Attenuation
ring). Hi-Mid bandwidth
i s (inside ring).
The
control selects the frequency
at which the treble equaliser
b a n d
continuously variable from
1KHz to 20KHz.
The Hi-Mid FREQUENCY
control selects the frequency
at which the hi-mid equaliser
b a n d a c t s a n d
continuously variable from
400Hz to 8kHz.
Front Panel Front Panel
T r e b l e B a n d
Gain/Attenuation (outside
ring). Treble bandwidth
(inside ring, activated when
Bell is selected).
(outside
Treble FREQUENCY
a c t s a n d i s
The Treble Band BELL switch
enables or disables
Parametric EQ for the treble
band. The Bell switch is a
conventional latching switch
- when depressed
equaliser band will work in
i s
f u l l p a r a m e t r i c
otherwise the equaliser band
will act like a traditional
MIDAS shelving response
EQ.
the
the
m o d e ,
