Mains switch
T h e m a i n s s w i t c h i s
conventional latching type switch,
which is on when depressed. The
action of the switch is firm but
does not require excessive force,
which may damage the unit. A red
LED is provided to the left of the
power switch to indicate that the
XL42 is receiving mains power.
Output section
EQ section
Input section
XL42 Operators Manual - Page 5
The XL42 is a highly featured 1U 19" rackmount dual channel
strip.The unit is split into two identical channel strips, each
with identical function but having independent inputs and
outputs.
