Installation
Establish the electrical
connection as follows:
Fig. 1
Fig. 3
10
5.2 Electrical connection
Danger: Only a qualified electrician is
allowed to work on the electrical connection.
Before establishing the connection, make sure
that the connecting cable is dead.
Fig. 2
Fig. 4
PE N
L
WILO SE 11/2011
