- Page 1 D-LED TV DVB-T2 OpEraTing inSTrucTiOn please read these instructions before operating your set and retain them for future reference. Model: S49D302B2...
-
Page 3: Table Of Contents
Contents WARNINGS AND PRECAUTIONS ........4 BUTTONS ON THE TV . -
Page 4: Warnings And Precautions
WARNINGS AND PRECAUTIONS Read all of the instruction before operating the set. Keep the instruction for later use. Warnings • Use only the attachments/accessories specified or provided by the manufacturer (such as the exclusive supply adapter, battery etc). • Please refer to the information on exterior back enclosure for electrical and safety information before installing or operating the device. - Page 5 WEEE Directive Correct disposal of the product. The symbol indicates that this product should not be disposed of with other household waste throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources.
-
Page 6: Buttons On The Tv
Precautions for Using Battery Inadequate use of batteries may cause leakage. Therefore, please follow the steps below and use them with care. 1. Please note the batteries polarity to avoid short circuit. 2. If the battery voltage is insufficient, which affects the remote control range, you should replace used batteries with the new ones. -
Page 7: Connections
cOnnEcTiOnS Terminals Note: The images are intended for reference only. 1. S/PDIF OUT: Use a digital optical cable to connect your TV to a compatible audio receiver. 2. USB1/USB2: USB port 3. HDMI1 (MHL)/HDMI2/HDMI3 IN: Connent HDMI input signal from source such as DVD, HDMI1 port supports MHL function. -
Page 8: Remote Control Functions
rEMOTE cOnTrOL FuncTiOnS remote control 1. POWER ( ) Press to turn the TV on or to put it in standby. 2. MUTE ( ) Press to mute or restore the volume. 3. PICTURE Change picture mode. 4. SOUND Change sound mode. 5. - Page 9 19. EPG Press to display the current EPG information in DTV mode. 20. SUBTITLE Enable/disable subtitles in DTV/USB mode. 21. FAV. (Favorite Channel) Press to view your assigned favourite channels. Press Up/Down buttons to move through your assigned favourite channels. Press ENTER to confirm.
- Page 10 Teletext Control Buttons 32. TEXT Press to enter or exit the teletext menu. 33. HOLD Press to hold the teletext page on screen without update and changes. Press again to release the hold state. 34. Other Buttons SIZE Enlarge the teletext display: Press this button once to enlarge upper half of the screen.
-
Page 11: Personal Video Recording (Pvr)
pErSOnaL ViDEO rEcOrDing (pVr) IMPORTANT NOTES: 1. For any type of recording with this television, you must connect an external device to the appropriate USB port at the back of the television to store the recorded files. 2. The USB device must be formatted in FAT32 file system. 3. -
Page 12: Electronic Programme Guide (Epg)
4. Choose the appropriate recording mode: once, every day or weekly. 5. Press ENTER to confirm your selection. A schedule of all your recordings (the schedule list) will appear. See EPG function for more on the schedule. If you are browsing the EPG, follow the steps provided on EPG function page. ELEcTrOnic prOgraMME guiDE (Epg) EPG stands for Digital Electronic Programme Guide. -
Page 13: Menu Settings
MEnu SETTingS Menu Operation (DTV Mode) Press “MENU” key to enter the main menu. Press the ] / [ ] guide key to select desired item. Press “ENTER” key to enter the item. Press [ ] / [ ]/ [] / [] and ENTER buttons to select the submenus. Press “MENU”... -
Page 14: Channel
channel Auto Tuning Select DVB-T or DVB-C and press ENTER button to go to the next step. Select country or scan type and then search and store programmes automatically. If you want to stop the auto search, press MENU button or EXIT button and exit dialog box will pop out. • Press ... - Page 15 1. Press or to select channel number and then press ENTER to start the search. 2. The search stops when programme is found and this program will be stored in the current channel position. If you want to stop the search, press the MENU button. ATV Manual Tuning First select the source type of ATV.
-
Page 16: Lock
OSD Language Select the OSD language. Audio Languages / Subtitle Languages (Note 1) Select the desired language. TTX Language Select TTX language for different regions. Time The following options can be adjusted: Auto Sync, Clock, Time Zone, Summer Time, Sleep Timer and Auto Sleep. -
Page 17: Usb Control
uSB cOnTrOL Bear in Mind when using uSB 1. Some USB storage devices may be somewhat incompatible with this TV. 2. Back up all data in USB storage device to prevent losing them due to an unexpected accident. We do not assume any liability for the losses due to misuse or malfunction. Data backup is consumer’s responsibility. - Page 18 Video File Type / (Ext Name) Video Type Audio Type Remark MP4, MOV / Motion JPEG MPEG-AUDIO (.mp4, .mov, .m4v) MPEG-4 SP/SP(XviD) Motion JPEG LPCM AVI / (.avi) MPEG-4 SP/SP(XviD) MPEG-AUDIO MS-ADPCM, ASF / (.wmv3, .xvid) MPEG-4 SP/ASP(XviD) Intel-ADPCM MKV / (.mkv, .xvid) MPEG-4 SP/ASP(XviD) MPEG-AUDIO LPCM...
-
Page 19: Usb Menu
uSB Menu Press Source menu and select USB button. You can play movie, music and photo files from your USB storage devices. 1. Connect USB storage device to USB input terminal and select the types of media on the home page: MOVIE, MUSIC and PHOTO. 2. -
Page 20: Play Music
play Music Press [ INFO ] / [ ] to display / exit from the below Menu Bar. Press USB control buttons on the remote control to perform the relevant operations. MUSIC CONTROL BAR Play & Pause / Stop / Previous / Next Press [/ ] to play or pause the playing;... -
Page 21: Browse Photo
Browse photo Press [ INFO ] / [ ] to display / exit from the below Menu Bar. Press USB control buttons on the remote control to perform the relevant operations. PHOTO CONTROL BAR Play & Pause / Stop / Previous / Next Press [/ ] to play or pause the playing;... -
Page 22: Troubleshooting
TrOuBLESHOOTing Before calling a service technician, review following information for possible causes and solutions for the problem you are experiencing. NO PICTURE, NO SOUND SNOWY DOTS AND INTERFERENCE 1. 1. Check if the fuse or circuit breaker is If the antenna is located in the fringe area of working. -
Page 23: Specifications
SpEciFicaTiOnS Screen size - diagonal 124cm Screen resolution 1920x1080 Audio output power (L+R) 8W + 8W Working voltage 100-240V~ 50/60Hz Rated power consumption 120W Dimensions (W x H x Dmm) 1102.7x685.7x264mm Net weight 12.7kg Environment Working temperature: 5°C~45°C (only for Tropical climates zone): Working humidity: 20%~80% Storage temperature: -15°C~50°C Storage humidity: 10%~90%... - Page 24 Model: S49D302B2...
