- Page 1 Residential space heating appliances fire d by: Wood and Lignite Alice Alice Alice Alice Gioia Mod. 480N Mod. 490N Mod. 490L Mod. 480L Mod. 470 USING INSTRUCTIONS AND MAI NTENANCE Equipments built in conformity with European Norms for marking : Cod.
-
Page 2: Table Of Contents
mod. 470-480L-490L-480N-490N GB Dear Customer, We thank You for Your preference; we try to built a product without default to make Your life easier, in any case we remember You to read this handbook before equipment using . To leave out the reading of this handbook has to be considered as “NOT CORRECT USE “... -
Page 3: Installation
mod. 470-480L-490L-480N-490N GB 1 INS TALLATION RES ERVED TO INS TALLER 1.1 Normative and prescriptions • Read carefully the contents of this handbook, it contains important information and instructions for installation, use, maintenance and product safety. • The appliance must be installed inside an environment considered suitable for installation and use by competent authorities. -
Page 4: Connection
mod. 470-480L-490L-480N-490N GB SECURITY DISTANCES • From flammable object : − A > 500 mm B > 200 mm C > 200 mm • From flammable object and from principal wall in rein forced concrete : − A > 1000 mm B >... - Page 5 mod. 470-480L-490L-480N-490N GB CHIMNEY OR FLUE • The chimney or flue should have the following characteristics: − It’ s advisable read, follow and respect what indicated in the paragraphe 1.1 − Good sel of combustion products, impermeable and completely insulated as normative condiction −...
- Page 6 mod. 470-480L-490L-480N-490N GB Inclination Roof Re Flux Area Highness Z ( m) C (°) 1,85 1,00 0,50 1,50 1,30 0,80 1,30 2,00 1,50 1,20 2,50 2,10 Re-flux Chimney pot area wind damping Chimney Revolving P ot Wind chimney pot for strong Damping horizontal wind...
- Page 7 mod. 470-480L-490L-480N-490N GB CONNECTION TO FLUE • The connect the heating equipment to the flue / chimney checking that the exhaust pipe don’t take up the free section of flue. • Employ only tubes supplied by seal gasket. • To not use horizontal tubes ( max 1 meter ) and curves. FEED AIR COMB USTION DIRECT FROM ENVIRONMENT •...
-
Page 8: Technical Details
mod. 470-480L-490L-480N-490N GB 1.5 TECHNICALS DETAILS DESCRIPTION Mod. GIOIA ALICE 480L 480N 490L 490N WIDTH DEPHT HEIGHT 1215 1190 EQUIPMENT WEIGHT Stell / Ceramic Stell / EQUIPMENT WEIGHT S.Stone Ø DIAMETER EXHAUST FUME TERMIC POWER OUTPUT NOMINAL POWER OUTPUT Wood/Lignite EMISSION OF CO : 0.29/0.20 0.10/0.11... -
Page 9: Using
mod. 470-480L-490L-480N-490N GB 2 US ING - RES ERVED TO US ER 2.1 Important warnings • To read carefully this section’s instruction which are very important for use, maintenance and appliance safety. • This handbook has to be ridden completely, in case of lack it can be consider an improper use of the equipment so a not right use of it. -
Page 10: Starting
mod. 470-480L-490L-480N-490N GB • To guarantee a perfect combustion it’s necessary to preserve the wood in a dry and clean place. • The wood thermic output is related to its humidity in %. (see the schedule ). 2.3 Starting • The appliance should set at work only after having completed the following operations: complete assembling, connection to exhaust fumes duct and to the heating plant. - Page 11 mod. 470-480L-490L-480N-490N GB IGNITION • To arrange on foyer a cube-lighting or a small quantity of paper, around 0,5 kg of wood in small pieces. Open entirely the prime and secondary air, light the paper and close the foyer door. •...
- Page 12 mod. 470-480L-490L-480N-490N GB LOADING - TO RESTART WITH EMB ERS ( Moderates flames ) In case of starting with embers, go on as follows : • Thicken the embers in the middle of the foyer . • Open totally the prime air. •...
- Page 13 mod. 470-480L-490L-480N-490N GB FIRE CONTROL • To obtain always a good compromise between the thermic performance and the combustible consumption, it’ s advisable to keep the following regulations : during the normal employing the fire intensity can be regulated employing the prime and secondary air lever.
-
Page 14: Maintenance And Cleaning
mod. 470-480L-490L-480N-490N GB 3 MAINTENANCE AND CLEANING RESERVED TO USER IMPORTANT WARNING • Every maintenance and cleaning operations must be done when the stove is light off and cold. • The stove’ s conditions must be checked by our qualify staff. 3.1 Ordinary maintenance •... - Page 15 mod. 470-480L-490L-480N-490N GB INTERNAL EXHAUST GAS FUMES CLEANING • At least one per year or every time it’s necessary • The inside cleaning must be done always when the stove is cold. All the necessary equipment should be prepared before operations. •...
- Page 16 mod. 470-480L-490L-480N-490N GB • N.B. To guarantee the correct stove functioning it’ s necessary recover then perfect seal between the sheet body and the cast iron top removing silicon residuals. Employ new silicon ( silicon resistant to high temperatures 300°÷350°) or employ a seal in fibro ceramic ( 10x3 ) in the position indicated in letter “...
-
Page 17: P Ossible Failure And Its Solution
Every intervention has be done from qualify staff ! Lincar S.p.A is not responsible for damages to thing or people due to a wrong installation, equipment tampering, improper use, bad maintenance or no observation of normative in force. - Page 18 mod. 470-480L-490L-480N-490N GB ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ 18/20...
