- Page 1 SKYROS SERIES IP Surveillance Camera DG-SC2600/DG-SC2600W V1.2 2012-11-27...
- Page 3 DIGISOL DG-SC2600/DG-SC2600W Surveillance Camera. DG-SC2600/DG-SC2600W is an IP surveillance camera with Mega pixel image sensor, H.264 compression and in-built microphone. The Mega pixel image sensors and H.264 compression help in streaming high quality video at low bandwidth. The easy to use utility and features like two way audio, motion detection and event triggers to email/FTP makes it an ideal choice for SOHO and SMB surveillance.
- Page 4 No pre-loaded software required - all you need is a browser like Internet Explorer 6 (and above, with plugin installed). With supplied SKYROS Manager software, you can connect up to 16 video cameras and view images captured by every camera at the same time.
- Page 5 WLAN LED Power LED LAN LED: Indicates LAN activity. WLAN LED: Indicates Wireless LAN activity (Not Applicable for DG-SC2600.) Power LED: Indicates power status. Camera: Video camera with lens. Focus Ring: Adjusts focus by rotating it to get a clear image.
- Page 6 Bottom view (Wired) Bottom view (Wireless) WPS: Click the button on IP Cam and click it on the AP you want to connect wirelessly. (Only applicable for DG-SC2600W) Reset to Default: Press and hold the reset button until all the LED’s on the camera go off so as to reset the camera settings.
- Page 7 SD Card Slot SD Card Slot: Accepts SD / SD-HC memory card for image / video storage. USB Port: Connects to certain wireless module. Antenna Base: Connects to supplied antenna. * The USB port on DG-SC2600 (Wired model) is for future application.
- Page 8 Camera Installation – Hardware Please follow the instructions mentioned below to set up your IP camera. 1. Unpack the product package and check if anything’s missing. 2. Connect the Ethernet cable to your local area network, and connect the other end to the LAN jack of this IP camera. NOTE: You can skip this step if you plan to use wireless LAN only.
- Page 9 Camera Installation – Software Insert the set up CD into your CD ROM drive of notebook/desktop computer. The CD will automatically run. Click on the ‘Install Administrator Utility’.
- Page 10 Click ‘Next’ to start the installation of SKYROS Camera Admin software. You can change the installation folder of camera setup software here, click ‘Browse’ to select an existing folder or you can just click ‘Next’ to use default installation folder:...
- Page 11 If you wish to create desktop icon and / or quick launch icon for camera admin software, please check corresponding box, and click ‘Next’ to continue. You’ll see a brief of all options you selected, click ‘Install’ to install camera admin software now or click ‘back’...
- Page 12 When you see this message, the installation of camera admin software is complete. If you wish to launch camera admin software now, keep ‘Launch Skyros Camera Admin Software’ box checked, and click ‘Finish’ to close installation utility. Once the camera admin software is launched, all cameras found on your local area network will be displayed:...
- Page 13 All camera-related information will be displayed here. If you wish to connect to a certain camera by web browser, double-click the camera listed here. Search camera: Click this button to search all cameras on the local area network again. Browse camera via web: Select a camera from the displayed list, and then click this button to connect to the camera by web browser.
- Page 14 Web Management of the Camera To access the web configuration of the camera, assign a static IP address to your notebook/desktop computer in the subnet 192.168.2.X with the subnet mask 255.255.255.0 and gateway at 192.168.2.1. For example, assign the IP address 192.168.2.10. ...
- Page 15 When you’re prompted, click ‘Run’ to continue. You should be able to see the images captured by the camera. Congratulations! Now you can start advanced Configuration.
- Page 16 Following are the solutions to problems that may occur during the installation and operation of the Digisol DG-SC2600/DG-SC2600W IP Surveillance Camera. 1. Cannot access the IP camera. Please make sure IP camera is correctly powered (the ‘Power’ LED should be on) ...
