Step 1

Assembly List

Item #
11
MAIN FRAME
12
REAR STABILIZER
19
HANDLE
46
HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 4 1/4
49
FLAT WASHER SAE B/O 3/8"
56
HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 3/4
60
HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 4
67
NYLON INSERT JAM LOCK NUT B/O 3/8-16
68
BLACK NYLON PULLEY 3/8 X 1 X 3 1/2
85
SPLIT LOCK WASHER B/O 3/8"
56
49
68
49
56
4
Description
49
67
49
67
68
49
60
Qty.
1
1
2
4
20
6
2
8
4
4
49
46
85
49
49
46
85
49
19
46
85
49
67
49
11
12
SPT-7 Six - Pak Light Commercial Trainer
19
67
