Figure 1: View of top / side / front
Function key
Babyalarm
ON/OFF
Control-LED
(located under
front cover)
Figure 2: View of underside
Sensitivity
control #1
English 10
Connection
socket #1 for
microphone
cable
compartment
Connection
socket #2 for
baby micro-
phone
Front cover
of battery
6 V-connection
socket
Sensitivity control
#2 for baby micro-
phone
