DKL400UY SLIDING GATE OPERATOR OUTLINE 1. Important safety precautions………………………2 2. Main features ………………………………………2 3. Main technical parameters ………………………2 4. Necessary Tools ……………………………………3 5. Site Preparation ……………………………………3 6. Mechanical Installation ……………………………4 7. Electrical ……………………………………………7 8. Tuning and operation ……………………………11 9. Check ………………………………………………14 10. - Page 3 DKL400UY SLIDE GATE OPENER...
- Page 4 DKL400UY MODEL: COMPONENT COMPONENT MFR’S PART NO. QUANTITY DESCRIPTION MANUFACTURER Cover tc3cov1 LOCKMASTER LOCKMASTER Set Phillips screw tc3sps2 1/2 h.p. Motor tc3mot3 LOCKMASTER Limit magnets LOCKMASTER tc3lm4 Control board tc3c/b5 LOCKMASTER tc3cap6 Capacitor LOCKMASTER L-brackets tc3lb7 LOCKMASTER Plastic clip LOCKMASTER...
-
Page 5: Important Safety Precautions
This work should only be performed by a trained technician. Miswiring could cause personal injury or DEATH. To prevent the risk of electrocution, be sure to turn off all power to the DKL400UY until installation is complete. The gate operator should be installed by a qualified technician; otherwise, serious personal injury or property damage may occur. -
Page 6: Necessary Tools
DKL400UY in the electrical section. The DKL400UY requires at least a 10A service. Make sure your electrician takes into account the voltage drop involved in running many feet of wire to your installation location. -
Page 7: Mechanical Installation
Fig.1 Installation and Adjustment The DKL400UY Chain-driven Gate Operator operates by forcing a straight piece of chain through its chain box. This length of chain is extended between two chain brackets located at opposite ends of the gate. The entire configuration is shown in the diagram above. - Page 8 DKL400UY SLIDING GATE OPERATOR Gate operator Socket head cap screw Chain box Operator base Anchor bolt Anchor Conduit Cable Concrete pad Fig.2 Chain Box Make sure the ends of the guide chain are out of the chain holes on both sides of the chain box.
- Page 9 DKL400UY SLIDING GATE OPERATOR Chain Brackets Use the appropriate bolts to attach the chain bracket to the frame of the gate. If the gate is of square frame style, use the square bolts shown. Gate Square frame Plain washer ( Φ 6) Square bolt Spring washer ( Φ...
-
Page 10: Electrical
DKL400UY SLIDING GATE OPERATOR Magnets for Limit Switch Install the magnet and magnetic limit switch as shown in Fig.7. The magnet and limit switch are used to control the position of the gate. When the magnet is installed, release the gear clutch and push the sliding gate manually to pre-determine the position. - Page 11 Step #1 Unscrew the Blue Cover from the Motor and set it aside. Open the small white box & make sure that the contents include: (1) - Receiver and (1) - Control Board Step #2 Install the Control Board onto the Motor by mounting it on the small white clips that are on the large Mounting Plate.
- Page 12 MAKING THE CONNECTION Step #4 Now you will begin the installation by screwing the wires that are coming from the small Receiver Board onto the Terminals (see Pic 1, right) from the Control Board, in the following order: Terminal 10 - GREEN WIRE Terminal 11 - RED WIRE Terminal 12 - YELLOW WIRE (any) Terminal 13 - YELLOW &...
- Page 13 Step #6 Find the plug with the Blue & Yellow wires on it. Connect the plug on to the Control Board on the section labeled: "CAPACITOR" (as shown on the pic, right) Step #7 Find the plug with the Red, White & Blue wires on it. Connect the plug on to the Control Board on the section labeled: "LIMIT SWITCH"...
-
Page 14: Tuning And Operation
AC SLIDE GATE CONTROLLER FEATURE SELECTOR Limit Switch Type DIP 1 ON: Normally Close OFF: Normally Open When using auto close features only one dip switch should be it h h ld b Auto Close Feature Auto Close Feature DI P 2 12.5 Seconds ON. - Page 15 Transmitter/Remote Control (shown in Figure 9) 1. Yellow Button Channel 2. Blue Button Channel 3. Indicator Light 4. Yellow Button Channel – exposed 5. DIP Switch 6. Battery 7. Blue Button Channel – exposed 8. Back side cover Figure 9 Receiver 1.
- Page 16 Residential Sliding Gate Operator Optional Equipment Installation Procedures Green Brown Black Blue Brown Black White Grey Grey Black Black...
-
Page 17: Check
DKL400UY SLIDING GATE OPERATOR 11. Trouble Shooting Trouble Possible causes Solutions The wire connector terminal block Check wire connector terminal block make becomes loose. sure it is plugged in terminal block 10 (X8). Check limit switch wire connector terminal The limit switch wire connector terminal block make sure it is plugged in terminal Motor only runs in one direction. - Page 18 Gate1Access LLC. P.O. box 120159 Clermont Fl. 34712 sales@openers4less.com www.Openers4less.com 2011-2012 Lockmaster All Rights Reserved...
