Canyon CNS-SW9 User Manual

Multi-functional watch device with digital compass function
Hide thumbs
Table of Contents

Advertisement

Quick Links

TABLE OF CONTENTS

1
2
2
3
3
4
5
6
7
8
9
10
11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CNS-SW9 and is the answer not in the manual?

Questions and answers

Abraham Haufmann
June 22, 2025

I want to buy it sport watch cns-sw9, have you got itt?

0

Related Manuals for Canyon CNS-SW9

Summary of Contents for Canyon CNS-SW9

  • Page 1: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION AFETY RECAUTIONS ACKAGE ONTENTS EVICE VERVIEW BASIC OPERATION URRENT AILY LARM HRONOGRAPH OUNTDOWN IMER ACER COMPASS FUNCTION...

  • Page 2: Introduction

    To fully utilize the functions and features of CANYON CNS-SW9, please read through the user manual carefully before using the product, and follow all of the procedures in the manual to fully enjoy all features of the product.

  • Page 3: Package Contents

    Package Contents Product Image Item Name CANYON CNS-SW9 Main Unit Quick Guide Documentation CD Device Overview Navigation Arrow LIGHT Button ST./STP. Button MODE Button LAP/RESET Button LED Display...

  • Page 4: Basic Operation

    Basic Operation CANYON CNS-SW9 is a multi-functional watch device that contains 7 functional modes including Current Time Mode, Daily Alarm Mode, Chronograph Mode, Countdown Timer Mode, Pacer Mode and Dual Time Mode. Press [MODE] to cycle through 6 functional modes and [LAP/RESET] to activate Compass Mode as shown...

  • Page 5: Current Time Mode

    Current Time Mode Press [ST./STP.] to toggle between Time Display and Date Display. Press and hold [ST./STP.] at Date Display to switch date format between Month-Date and Date-Month. Press and hold [MODE] for 2 seconds to enter Settings Mode. Press [MODE] to shift through different digits and settings.

  • Page 6: Daily Alarm Mode

    Daily Alarm Mode Press [ST./STP.] to switch daily alarm on/off. A daily alarm indicator will be displayed on the screen. The alarm will ring continuously for 30 seconds. Press [LAP/RESET] to switch hourly chime on/off. An hourly chime indicator will be displayed on the screen.

  • Page 7: Chronograph Mode

    Chronograph Mode Upon entering, the Chronograph Mode indicator CHR will be displayed at the top of screen. The device measures elapsed time and current split time. Press [ST./STP.] to start counting. Press the button again to stop counting and the elapsed time will be displayed on the screen.

  • Page 8: Countdown Timer Mode

    Countdown Timer Mode Upon entering, the Countdown Timer Mode indicator CDT will be displayed at the top of screen. Press [ST./STP.] to start countdown. The residual time will be displayed on the screen. Press [ST./STP.] during count- down to pause. Press the button again to resume countdown.

  • Page 9: Pacer Mode

    Pacer Mode Upon entering, the Pacer Mode indicator PCR will be displayed at the top of screen. Press [ST./STP.] to generate beeps at a pre-defined pacer rate. Press the button again to stop. Press and hold [MODE] for 2 seconds to enter target time setting. Press [ST./STP.] and [LAP/RESET] to adjust values.

  • Page 10: Dual Time Mode

    Dual Time Mode Press and hold [MODE] for 2 seconds to enter Settings Mode. Press [MODE] to shift through different digits and settings. Press [ST./STP.] and [LAP/RESET] to adjust values. Press [MODE] after 12/24 hour format settings to save modified settings and exit Settings Mode.

  • Page 11: Compass Function

    Compass Function Precautions: Please keep the device away from all magnets or appliances that generate magnetic fields such as mobile phones, speakers, motors, etc. The device, like most magnetic compass, points to the magnetic North which is slightly different from the true North. Please refer to section below for more details.
  • Page 12 The angular difference between Magnetic North Pole and True North Pole is called magnetic declination. Its magnitude (in units of degrees and minutes) and direction (East or West) are dependent on the location of device. For users who intend to perform accurate navigations, device must be adjusted to compensate magnetic declination.
  • Page 13 NOTE: Please observe Precautions section and check up magnetic declination values from chart above or websites provided before perform compass calibration. To calibrate compass function, press and hold [MODE] for 2 seconds to enter compass calibration settings. Upon entering, the magnetic declination indicator DEC will be displayed at the top of screen.
  • Page 14 The direction of an object can be represented in term of either compass direction or compass bearing. The compass directions are North, Northeast, East, Southeast, South, Southwest, West, and Northwest. The compass bearing direction of an object is defined as the angular difference between North and the object while assuming 0˚...
  • Page 15 To take a compass measurement: NOTE: Please make sure that the device is parallel to horizon to acquire the most accurate measurement. Turn the device until the navigation arrow is pointing at the direction of desired object for measurement. Press [LAP/RESET] to enter Compass mode and to display corresponding compass direction and compass bearing.
  • Page 16 Press [ST./STP.] to fix/release current compass readings. The compass lock indicator will be displayed at the top of screen. The compass lock will be released automatically once the device enters standby mode or manually switched back to Current Time Mode.
