Summary of Contents for Champion 100199

  • Page 2: California Proposition 65 Warning

    No part of this publication may be reproduced or used in any form by any means – graphic, electronic or mechanical, including photocopying, recording, taping or information storage and retrieval systems – without the written permission of Champion Power Equipment (CPE). Have questions or need assistance?

  • Page 3: Table Of Contents

    Operating Hazards ..... . .7 This manual must be used with Champion Power Equipment Accidental Starting ..... . .8 (CPE) manuals: Carbon Monoxide Hazards .

  • Page 4: Introduction

    Model 100199 introduction Congratulations on your purchase of a Champion Power Equipment (CPE) home standby generator. This generator is designed and engineered in the USA to exacting standards of the North American market. This engine-powered generator meets all Environmental Protection Agency (EPA) Phase 3 requirements and is approved by as tested to UL2200 and CSA22.2 No.

  • Page 5: Safety

    . Electrical shock hazard Entanglement hazard Fire hazard © 2015 Champion Power Equipment Part No. 101049 Rev. A...

  • Page 6: Installation Hazards

    Model 100199 safEty installation HazarDs Explosion hazard Warning Have only a qualifi ed electrician or installation technician who is familiar with applicable codes, Burn hazard standards and regulations install and service the generator. ALWAYS comply with local, state and national electrical and building codes when installing the generator.

  • Page 7: Before Starting

    NEVER climb or step on any part or and judgment make operating a components of the generator. Doing generator dangerous. so may result in injury and cause leaking fuel and exhaust. © 2015 Champion Power Equipment Part No. 101049 Rev. A...

  • Page 8: Accidental Starting

    Model 100199 safety aCCiDEntal starting Carbon MonoxiDE HazarDs Warning DangEr ALWAYS prevent the generator from Generator exhaust contains carbon starting while the covers are open. monoxide, a colorless, odorless, The generator may crank and start poisonous gas. Breathing carbon at any time without notice. Follow...

  • Page 9: Electrical Shock Hazards

    If the victim is unconscious, apply first aid and call 911 immediately. © 2015 Champion Power Equipment Part No. 101049 Rev. A...

  • Page 10: Burn Hazards

    Model 100199 safety burn HazarDs Warning Warning Batteries contain sulfuric acid and generate explosive mixtures of hydrogen and oxygen gases. Keep ALWAYS allow hot surfaces to cool to any device that may cause sparks the touch. Running engines produce or flames away from the battery to heat.

  • Page 11: Safety, Serial/Model, Nameplate Label Locations

    The safety labels have specifi c placement and must be replaced if they are unreadable, damaged or missing. A) Serial number locati on B) Nameplate © 2015 Champion Power Equipment Part No. 101049 Rev. A...

  • Page 12: Safety Labels On Unit

    Model 100199 safEty safEty labEls on unit Poisonous Gas Hazard Generator exhaust Fire Hazard ALWAYS keep the surrounding contains carbon monoxide. Breathing carbon area near generator clean and free of debris Burn Hazard DO NOT Burn Hazard DO NOT touch hot monoxide will cause nausea, dizziness, and and/or dry vegetation.

  • Page 13: Specifications

    Engine start sequence Standard Starter lockout Standard Battery charger/low battery indicator Standard Charger fault Standard AVR over voltage protection Standard Low oil protection Standard Safety fused Standard Overcrank/overspeed/underspeed protection Standard © 2015 Champion Power Equipment Part No. 101049 Rev. A...

  • Page 14: Standards

    Model 100199 stanDarDs NFPA No. 54, NATIONAL FUEL GAS CODE Warning National Fire Protection Association 470 Atlantic Avenue Have only a qualified/certified Boston, MA 02210 electrician or installation technician NFPA No. 58, AMERICAN NATIONAL STANDARD FOR STORAGE who is knowledgeable about...

  • Page 15: Unpacking

    Inspect the generator for damaged or loose parts. DO NOT operate the generator if any components are damaged or loose. Contact your dealer for assistance. © 2015 Champion Power Equipment Part No. 101049 Rev. A...

  • Page 16: Installation

    Model 100199 installation Mounting arEa Before installing the generator, review SAFETY section starting page 5 Make sure you have completed transfer switch evaluation and Have the generator installed by an authorized CPE dealer. Install installation location before securing the generator. The generator the equipment in compliance with the National Electrical Code is 49.1 in.

  • Page 17: Earth Ground

    Maximum fl ow rate 146,667 Btu/hr 135,760 Btu/hr nominal fuel rating EnginE oil 2500 Btu/ft Check the engine oil level. See the operator’s manual for oil 1000 Btu/ft specifi cations. © 2015 Champion Power Equipment Part No. 101049 Rev. A...

  • Page 18: Fuel Pipe Size

    Model 100199 installation fuEl PiPE sizE Install the LPG jets in the mixing valve. Tighten the low- speed jet to 15.9-22.1 lb-in. (1.8-2.5 N·m) and the main jet to 10.6-13.2 lb-in. (1.2-1.5 N·m). NOTICE Install the fuel hose and tighten the clamp securely. Be sure to check the connection for fuel leaks after installing Reduced pipe size will affect fuel delivery and performance.

  • Page 19: Battery

    ConnECting tHE fuEl suPPly Cont . Champion requires two (2) 12 volt batteries with a minimum of 18 Ah with a minimum of 270 CCA each. [battery size: 6-7/8 L x 3-7/16 W x 6-1/8 H inches (175 mm L x 87 mm W x 155 mm H)].

  • Page 20: Test-Starting The Engine

    Model 100199 installation tEst-starting tHE EnginE Caution Make sure that all tools and other objects are removed from the unit before starting the engine. It is recommended to start and run the engine for proper operation. NOTICE Be sure the engine has the correct amount of engine oil before starting the engine.
  • Page 22 Champion Power Equipment 12039 Smith Ave. Santa Fe Springs, CA 90670 USA Made in China...
