LED 3.3' Light Bar
DSY-LED252-IP65-RGB
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DSY-LED252-IP65-RGB and is the answer not in the manual?

Questions and answers

Related Manuals for Eddylight DSY-LED252-IP65-RGB

Summary of Contents for Eddylight DSY-LED252-IP65-RGB

  • Page 1 LED 3.3’ Light Bar DSY-LED252-IP65-RGB USER MANUAL...

  • Page 2: Safety Information

    1. Introduction Thank you for purchasing our LED 3.3’ Light Bar. Please read these instructions carefully before operating to avoid any possible damage and accidents caused by misuse. The LED 3.3’ LED Light Bar has an extruded aluminum shell. Three colors of high-brightness LED lights (red, blue, green) are used to create a wide spectrum of colors.

  • Page 3: Dimensions And Specifications

    3. Dimensions and Specifications Weight: 3 Kg (6.6 lbs) Total Wattage: 35 W Intensive brightness LEDs: 252 pcs 10mm LEDs (108 red, 72 green, 72 blue) Beam angle: 35 deg beam angle of each LED Power supply: Voltage: 90-250 VAC Frequency: 47-63 Hz Power Consumption: 50 VA Fuse: T2A...

  • Page 4: Dmx Channel Assignment

    4. DMX Channel Assignment DMX Value Function Notes 0-24 Solid color Uses color values Uses color values of CH 2-13 of CH 2-13 25-74 Strobe; speed value 75-99 Color fade; speed Overrides color Overrides color Overrides color Overrides color Overrides color Overrides color Overrides color values and uses...
  • Page 5 5. Rear Panel Display and Operation MENU: Access the menu or return to a previous menu option UP: Menu selection or parameter increments DOWN: Menu selection or parameter increments ENTER: Select the current menu option (not present on some models) 6.
  • Page 6 For example, if you want to choose DMX mode A001, operate as follows: • Press MENU, to go back to the main menu • Press UP / DOWN until “Addr” • Press ENTER to choose, the display will blinking • Press UP / DOWN to change the address code to select “A001” •...
  • Page 7 Color Name Green Blue     Green   Blue   Amber   Cyan   Magenta   White Color Name Green Blue   White   Dim White     Orange   Yellow   Chartreuse   Spring Green   Cyan   Blue  ...

  • Page 8: Master/Slave Control

    7. Master/Slave Control The MASTER functions as a master as long as it’s not in DMX mode (and ideally no cable plugged into the DMX INPUT on the unit). It sends a signal to the SLAVE through a DMX cable and synchronizes its settings to it.
