Summary of Contents for Zebex Z-2242
- Page 1 Z-2242 GLLS User’s Manual Android Handheld Computer...
- Page 3 ’ ANUAL Revision History Changes to the original manual are listed below: Version Date Description of Version 2015/12/25 Initial release Android Handheld Computer...
-
Page 4: Regulatory Information
Regulatory Information Caution: Only use ZEBEX approved accessories. Wireless Device Country Approval Regulatory markings, subject to certification, are applied to the device signifying the radio(s) are approved for use in the European countries under CE coverage. - Page 5 ’ ANUAL Ad-Hoc Operation ( 5GHz Band ) Ad-Hoc operation is limited to Channels 36- 48 ( 5150 – 5250 MHz) . Use of this band is restricted to indoor use only, any other use will make the operation of this device illegal. Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules.
-
Page 6: Warnings Of Use Wireless Devices
These requests are designed to prevent possible interference with sensitive medical equipment. Safety Information – Europe This device was tested for typical body-worn operation. Use only ZEBEX tested and approved accessories to ensure EU compliance. Android Handheld Computer... - Page 7 Power Adaptor Use only a Z-2242 approved Power Adaptor with electrical ratings : Output 5VDC, min 2A, with a maximum ambient temperature of at least 45℃. Use of alternative power adaptor will invalidate any approvals given to this device and maybe dangerous.
-
Page 8: Guidance For Printing
’ ANUAL Do not leave or store the equipment in or near areas that might get very hot, such as in a parked vehicle or near a radiator or other heat source. Do not place battery into a microwave oven or dryer. ... -
Page 9: Table Of Contents
’ ANUAL Table of Contents Important Notice........................ii Regulatory Information ..................ii Warnings of Use Wireless Devices ..............iv Guidance for Printing ..................vi Getting Started........................1 Product Overview......................1 Accessory Options......................2 Using the Device......................3 Charging the battery ....................3 Power On the Device....................4 MicroSD / MicroSIM Card Installation..............4 LED Status ......................5 Power Button .......................5 Scan a Barcode .....................6... -
Page 11: Getting Started
’ ANUAL Getting Started Product Overview Android Handheld Computer... -
Page 12: Accessory Options
’ ANUAL Accessory Options CRD-40 (Docking station): The Class III Docking station (CRD-40) shall be powered by an LPS power supply. Android Handheld Computer... -
Page 13: Using The Device
’ ANUAL Using the Device Charging the battery Before using the device, charge the battery using one of the following accessories approved by the manufacturer: Micro USB cable through PC Micro USB cable + Power Adaptor Jack Cradle Charging + DC Power Cable + Power Adaptor Jack Note: LED shows solid red when charging and will turn to green when fully charged. -
Page 14: Power On The Device
’ ANUAL Power On the Device Press the power button to turn on the device. MicroSD / MicroSIM Card Installation 1. Open Micro SD/Micro SIM door. You will find 2 trays inside the slots. 2. Locate the hole on top of the trays and insert a pin inside to remove the trays. 3. -
Page 15: Led Status
’ ANUAL LED Status Indication Solid green Charging complete Solid red Charging in progress Solid blue Bluetooth in use Red flashing Charging temperature over the 0~45°C range. Charging is stopped temporarily as a safety measure Power Button Power Off To Power off the device, press and hold the button until the device options dialog box appears, then touch Power off. -
Page 16: Scan A Barcode
’ ANUAL Scan a Barcode 1. Launch a barcode reading application. 2. Set the scan key to barcode scan. 3. Point the exit scan window of the device at the barcode. 4. Press the scan button. The red laser aiming pattern turns on to assist in aiming, scan ready when beep sounds. -
Page 17: Key Operations
’ ANUAL Key Operations Return Menu Home Press Menu shortly to pop up the functional menu of the current application. Press Home to return to the home screen from any operation interface. Press Return to return to the previous screen. GPS Information ... -
Page 18: Using The Touch Screen
’ ANUAL Using the Touch Screen The device uses a Multi-Touch screen. Swipe your finger across the screen or tap an icon to provide input to the device. Tap items on the screen to select them; press the back key to go back to the previous step. -
Page 19: Home Screen
’ ANUAL Home Screen The Home Screen contains a status bar, shortcut icons, and a dock bar. The home screen allows up to five pages for placing shortcut icons and widgets. You may customize the home screen according to your preferences. Tap to manage phone Tap to enable/disable calls... -
Page 20: Add Apps To Home Screen
’ ANUAL Add Apps to Home Screen 1. On the home screen you would like to customize, tap 2. Locate the app to add. 3. Tap and hold the app icon. The home screen will appear. 4. Drag the app icon to your preferred position and release to have it placed. Note: To remove an app from Home Screen, drag the icon from home screen to “X Remove”... -
Page 21: Near Field Communication (Nfc) Feature
’ ANUAL Near Field Communication (NFC) Feature Allow Data exchange in short-range (less than 4cm) when the phone touches another device. The NFC areas, being of both a phone and other NFC compatible device (ex: tags, reader, phones and so on.), should be close to one another for communication. NFC Detection To enable NFC features: 1. -
Page 22: General Settings
’ ANUAL General Settings Factory Data Reset Select “Settings”Backup & reset””Factory Data reset” on the device. Tap “Reset phone” to delete all data and restore back to your device’s factory settings. Note: Please plug in the device before doing a reset. Warning: Resetting your device will delete all data and content, including your Google account, downloaded files, and all your settings. -
Page 23: Data Capture Options
’ ANUAL Data Capture Options Turn on Barcode Scan 1. Switch on the barcode function by going to “Settings” “Barcode Scan” 2. Slide Barcode Scan to “ON”. Set Preferences 1. Slid Keyboard Simulation to “On” or “Off” depending on your needs. 2. -
Page 24: Set Scan Keys
’ ANUAL Set Scan Keys Scan Key (P1) (P2) 1. Go to “Settings” Select “Remap button & Shortcut” 2. Select “P1” and select “Remap Key”. 3. Choose “Barcode Scan”. 4. Select “P2””Remap Key” “Barcode Scan”. Android Handheld Computer... -
Page 25: System Settings
’ ANUAL System Settings Select “Settings” in the APPS menu. Note: Except for special notes, the setting of this device means: If the icon on the right side is displayed as OFF it indicates this option is disabled. If the icon on the right side is displayed as ON, it indicates this option is enabled. Wireless &... -
Page 26: Advanced Settings
’ ANUAL Instructions to connect with Wi-Fi network Click the Wi-Fi network in the list, and input the network password (if it is required) in the popup window. After the connection is successful, it will show the message like “Has connected to …”... -
Page 27: Bluetooth Operation
’ ANUAL Bluetooth Operation Enable/Disable Bluetooth To enable/disable Bluetooth, tap to turn the Bluetooth on or off on the right side. By default, Bluetooth visibility of the device is turned off. Tap the device at the top of the screen to turn on Bluetooth visibility. The status will change to Visible to all nearby Bluetooth. -
Page 28: Sim Card Switch
’ ANUAL Ethernet Configuration Use this option to configure proxy and IP settings for your Ethernet. SIM Card Switch To select a different SIM card, select “Settings” ””SIM card switch” ”Choose SIM card” and select “SIM Card 1” or “SIM Card 2”. Android Handheld Computer... -
Page 29: Sound
’ ANUAL Sound Volumes Adjust the volume by moving the slider left or right. Music, video, games, & other media Adjust the volume of media. Ringtone & notification Adjust the volume of incoming calls or messages. Alarms Adjust the volume of alarm clock. -
Page 30: Display
’ ANUAL Display Brightness Adjust the screen brightness. If the Auto Adjustment of Brightness is selected, the system will adjust the brightness automatically. If it is not selected, you can manually move the slider to adjust it. Wallpaper Select a photo as your wallpaper. Auto-rotate screen If this option is selected, the screen will switch to the landscape mode when rotating the angle of this device. -
Page 31: Location Access
’ ANUAL Location Access Access to My Location Enable this option to allow apps that have asked your permission to use your location information. GPS satellites Enable this option to let apps pinpoint you location. Wi-Fi & mobile network location Enable this option to let Google estimate your location faster. -
Page 32: Security
’ ANUAL Security Screen Lock None No screen lock. Slide Uses the default slide gesture to unlock a locked screen. Pattern Enter a pattern to use for unlocking the screen. PIN Uses the PIN code to unlock a locked screen. ... -
Page 33: Accounts
’ ANUAL Text-to-speech Output Sets the language-specific voice for the spoken text. Pointer Speed Slide to set the pointer speed. Accounts Change the settings of auto synchronization function or manage the accounts in need of synchronization. Add account Add, delete or modify the settings of accounts. Backup &... -
Page 34: Specification
’ ANUAL Specification SYSTEM Qualcomm Dual Core 1.5GHz Operating Android 4.2.2 System Memory 1GB RAM & 8GB ROM Display:4.5” TFT 720(w) × 1280(H) LCD; Display Touch Panel: Capacitive type ; 5-point multi-touch; 3-axis accelerometer Proximity sensor Ambient light sensor Sensor Magnetometer Gyroscope Scanner... - Page 35 ’ ANUAL RFID 13.56 MHz NFC ; Support NFC read & write function. GPS / A-GPS / GLONASS POWER Battery 3,450 mAh (3.7V / Non-removable) Charging time Max. 4 hours (1) AC adaptor charging (via micro USB) Charging (2) Docking station charging (no sleeve charging) method (3) Wireless charging (Support QI wireless charging cradle) Adapter Input AC100~240C, 50~60 Hz...
