Zebex Z-2060 series User Manual

Handheld computer
Hide thumbs Also See for Z-2060 series:
Table of Contents

Advertisement

Quick Links

Download this manual
Handheld Computer
Z-2060

User's Manual

series
RESET
ENT
ESC
1
abc
4
jkl
7
stu

ZEBEX INDUSTRIES INC.

WWW.ZEBEX.COM

( Version 3.00 )
SCAN
ENT
BS
F1
2
3
def
ghi
F2
5
6
mno
pqr
F3
8
9
yz
vwx
F4
0
@
SP

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Z-2060 series and is the answer not in the manual?

Questions and answers

Related Manuals for Zebex Z-2060 series

Summary of Contents for Zebex Z-2060 series

  • Page 1: Preface Handheld Computer

    Handheld Computer Z-2060 series ( Version 3.00 ) User’s Manual SCAN RESET ZEBEX INDUSTRIES INC. WWW.ZEBEX.COM...

  • Page 2: Revise The Picture Of Package Contents

    Adding the instruction of Using PowerPack Ver 2.00 2009/3/2 26~52 Adding the picture of How to order Ver 2.00 2009/3/2 53~56 Ver 3.00 2010/1/25 26~49 Updated PowerPack Functions and pictures Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 2 / 58...

  • Page 3: Table Of Contents

    A triangular shape indicates you should exercise caution........9 Copyright........................10 ZEBEX Industries Inc. makes no warranty of any kind with regard to this material. Including but not limited to the imply warranties of merchantability and fitness for a particular purpose. ZEBEX Industries Inc. shall not be liable for errors contained herein or for incidental consequential damages in connection with the furnishing, Performance or use of this product.
  • Page 4 Press to add a tab indention..................18 SP ........................... 18 Space key ........................18 Press to add a space character.................. 18 Inserting the Battery..................... 19 Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 4 / 58...
  • Page 5 Remove the SD Card ....................26 About The Product ....................... 27 Prerequisites ......................... 27 Specifications ....................... 28 Model..........................28 Z-2060 series ......................... 28 System ........................... 28 CPU ..........................28 Inter PXA 270 processor (Max. 520MHz)..............28 RAM..........................28 128 Mbyte ........................28 F-ROM ..........................
  • Page 6 Using Barcode Scanner ....................29 Scanning Barcodes ...................... 29 To scan a barcode: ....................... 29 1. Hold the Z-2060 horizontally and point it directly at the barcode you wish to Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 6 / 58...
  • Page 7 29 2. Once in the correct position, press the SCAN button........... 29 An audible alarm is heard and the barcode digits will appear on the ..... 29 Using the Zebex PowerPack..................29 Using the Zebex PowerPack..................30 Backlight........................30 Calculator ........................
  • Page 8 This information is good for identify device firmware version for future update or maintenance........................48 Function Key Manager ....................49 How to order........................54 Please offer Part Number or Model Name for next purchase........54 Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 8 / 58...

  • Page 9: Z-2060 Series Handheld Computer

    ZEBEX INDUSTRIES INC. Preface About This Manual Thank you for your purchase of the ZEBEX Z-2060 series handheld computer. ZEBEX Z-2060 series product is at the forefront of handheld computer technology, and this manual will provide the necessary information on the many and varied options available to you.

  • Page 10: Copyright

    Performance or use of this product. ZEBEX Industries Inc. will be under no liability in respect of any defect arising from fair wear and tear, willful damage, negligence, abnormal working conditions, failure to follow the instructions and warnings, or misuse or alteration or repair of the products without written approval.

  • Page 11: Safety Operation

    WARNING Disassembly and Modification Never try to disassemble or modify the device in any way. All servicing should be carried out by qualified Zebex personnel or Zebex- approved engineers. Interior Parts and Components Never touch interior high voltage parts or components. Doing so creates the danger of electrical shock.

  • Page 12: Federal Communication Commission (Fcc) Statement

    End users must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 12 / 58...

  • Page 13: Package Contents

    Mobile Data Terminal Stylus Pen Mini USB cable (Terminal to PC USB port) Sling for stylus Pen RS-232 DB9 (F) Cable Hand Strip Hand strip Holder Battery Pack Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 13 / 58...

  • Page 14: Optional Parts

    ZEBEX INDUSTRIES INC. Optional Parts Cradle package Docking Cradle RS232 cable AC Adapter USB cable (Cradle to USB) Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 14 / 58...

  • Page 15: Purchaseable Accessories

    AC Adapter Britain Plug head RS232 Cable U.S. Plug head RS-232 DB9 (F) Cable Australia Plug head USB cable (Cradle to USB) Europe Plug head Battery Pack Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 15 / 58...
  • Page 16 ZEBEX INDUSTRIES INC. Stylus Pen Sling for stylus Pen Hand Strip Hand strip Holder Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 16 / 58...

  • Page 17: General Guide

    This port is for RS-232 communication with PC Stylus pen For touch screen operation and press RESET switch. Hand strip Protects the Handheld Terminal to drop. Battery Main battery Sling for stylus pen Sling Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 17 / 58...

  • Page 18: Arrow

    4. Press after SF/Fn key and press F1-F4 key to perform F5 - F8 key. Tab key Press to add a tab indention. Space key Press to add a space character. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 18 / 58...

  • Page 19: Inserting The Battery

    Inserting the Battery Insert the battery pack as shown and watch the battery direction.. Remove the Battery Push the side lock to pick up the battery pack. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 19 / 58...

  • Page 20: Charging The Battery

    Charging by cable Connect the charging cable and AC adaptor as shown. Charging by cradle AC Power USB Interface Adapter Jack In RS232/COM port Interface Cradle - rear view Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 20 / 58...

  • Page 21: Cradle - Front View

    Right LED - The LED lit when the cradle is connected to AC power. Charging the battery separately in the cradle Insert the battery into the compartment at the rear of the cradle. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 21 / 58...

  • Page 22: Connect The Power Jack To The Cradle And Plug Ac Adapter Into The Socket

    Connect the power jack to the cradle and plug AC adapter into the socket. NOTES When charging the battery for the first time, charge for at least 12 hours prior to use. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 22 / 58...

  • Page 23: System Reset

    Cold reset will erase ALL pre-configured data on the scanner. Check carefully to make sure you have uploaded all important files to your PC before proceeding with the reset. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 23 / 58...

  • Page 24: Pc System Requirements

    RS232/COM interface connector on the cradle and the other to the COM1 port on your PC. 1. Or can use attach one RS-232 cable to connect with your computer’s COM port directly. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 24 / 58...

  • Page 25: Connecting Via Usb Cradle

    You can connect the Z-2060 directly to your PC, without the need for the cradle, using the Mini USB cable, attaching it to the port on the left hand side of the device. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 25 / 58...

  • Page 26: Inserting Sd Card

    1. Make sure the power is turn off. 2. Open the SD Slot cover as shown, Take off the SD card. 3. Closed the SD slot cover. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 26 / 58...

  • Page 27: About The Product

    The following skills or experiences are also desirable. ● Windows CE devices ● ActiveSync ● Something networking experience. Hardware Required The following models of the ZEBEX Z-2060 series and the dedicated options are available. Available models and the features: Model name Barcode scanner Bluetooth IEEE802.11b/g...

  • Page 28: Specifications

    CE & FCC Part 15B, 15 C,CE RF,LVD,ESD Cradle Single slot USB / RS-232 charging cradle with spare battery slot Microsoft VC 6.0 development environment Software &Development Supports SDK for program development Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 28 / 58...

  • Page 29: Scan

    2. Once in the correct position, press the SCAN button. An audible alarm is heard and the barcode digits will appear on the LCD screen if the scan is successful. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 29 / 58...

  • Page 30: Using The Zebex Powerpack

    ZEBEX INDUSTRIES INC. Using the Zebex PowerPack To save your time and effort in developing applications on Z-2070, ZEBEX provides it’s owndesign system management tool to called “PowerPack” to let you control it directly. The PowerPack management tools which installs in each of our WinCE product.
  • Page 31 Always OFF: This function can set up the backlight to be always off. 3. Brightness Control Bar The brightness of the backlight can be changed via control bar. Put up to light and put down to dark. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 31 / 58...

  • Page 32: Calculator

    : Division function. : Multiplication function. ＊ : Subtraction function. － : Addition function. ＋ : A decimal point of dot. ﹒ ＝ :To be equal to, The amount. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 32 / 58...

  • Page 33: File Transfer

    : For disconnecting with current devices. 2. Select Transfer File Select file need to be transferred, press bottom for selecting file. Start Transfer : Start transferring file to targeted devices. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 33 / 58...

  • Page 34: Ex. File Transferred Operation By Using Bluetooth

    1.2 Select Bluetooth devices for receiving file, select “ Connect ” for connecting with devices, or select “ Disconnect ” to disconnect with current devices. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 34 / 58...
  • Page 35 1.3 Click ” … ” bottom to select the file need to be transferred, then click ” OK ” bottom to confirm. 1.4 Select “ Start Transfer ” bottom to start file transferring. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 35 / 58...

  • Page 36: Preload Manager

    ZEBEX INDUSTRIES INC. Preload Manager The Preload Manager is an auto execution program for ZEBEX’s WinCE device. You may set programs into the Preload list box and running the program by automatically or manually. 1. Modify Window located on top of display, providing functionalities of Priority, Remove and Browse.

  • Page 37: Preload Operation

    Programs can be selected more than once. Confirming file by clicking “OK” will get back to Preload Manager main page. Then complete its process. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 37 / 58...
  • Page 38 Therefore, play music.exe will be shifted up. 2.2 Then select by clicking check everything program and click “Down” bottom. Therefore, check everything program will be shifted down. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 38 / 58...
  • Page 39 ZEBEX INDUSTRIES INC. 3. Remove a program: In order to remove “open explorer” program, select by clicking program, then select “Remove” by clicking on bottom to finish command. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 39 / 58...

  • Page 40: Switch

    The available wireless network access point will be searching automatically when you check the selection for enable WiFi function. You can select an access point and press “ ” button to connect with that network. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 40 / 58...
  • Page 41 You also can use " " or " " button for display more information for network setting. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 41 / 58...

  • Page 42: Trayscan

    Below are instructions of functions on main page: 1. Output Mode Providing three output methods such as Copy & Paste / Key Emulation / None (Copy to Clipboard). Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 42 / 58...

  • Page 43: 1.1 Copy & Paste

    To set the barcode parameter value of each kind of barcode for barcode scanner. Press the" Setting " button in TrayScan application to start the barcode setting. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 43 / 58...

  • Page 44: To Check The Barcode Type Selection For Enable The Type Of Barcode For Read

    " button to setting the barcode parameter value of each kind of barcode. Press " "button to use system default value to set up the barcode parameter. The default value was show in below pictures. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 44 / 58...

  • Page 45: The Default Values Of Ean/Upc Code And Code39

    ZEBEX INDUSTRIES INC. The default values of EAN/UPC code and Code39. The default values of ITF 2 of 5 code and Code128. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 45 / 58...

  • Page 46: Backup/Restore

    Flash Disk when there is no storage card. When Mini SD Card was installed into devices, program will auto-search and provides selection of SD Card from menu. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 46 / 58...
  • Page 47 ZEBEX INDUSTRIES INC. Backup : Select backup data as saved devices, press ” Backup ” bottom to proceed backup. Display will restore when backup was finished. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 47 / 58...

  • Page 48: Firmware Information

    PowerPack utility. You can find this application is located on path " \settings\control Panel\". This information is good for identify device firmware version for future update or maintenance. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 48 / 58...

  • Page 49: Function Key Manager

    F1: SIP ON/OFF。 F2: Backlight Manager。 F3: Power Switch。 F4: Calculator.exe。 F5: Volume + 。 F6: Volume -。 F7: Backlight +。 F8: Backlight -。 Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 49 / 58...
  • Page 50 Volume + Volume – Backlight + Backlight – Copy Paste Program File : Install application program according to demand, this function can be used for setting up auto-execution. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 50 / 58...
  • Page 51 1.1 Select items need to be modified, select by clicking ” Edit ” bottom to enter set up window as below: 1.2 Select new functional item and complete editing. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 51 / 58...
  • Page 52 2.1 Select Program File item，then click ” Browse ” bottom to enter File Opening Window. 2.2 Select software required auto-execution, then select ” OK ” bottom to complete selecting process. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 52 / 58...
  • Page 53 ” OK “ bottom to complete editing process. When Function Key Manager Main Page reappear on the display, F1 on function key item lists had been updated to testkeypadChar. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 53 / 58...

  • Page 54: How To Order

    ZEBEX INDUSTRIES INC. How to order Please offer Part Number or Model Name for next purchase. 1. Z-2060 Series Windows CE.NET Handheld Computer Set. Part Number Model Name Description Windows CE.NET Handheld Computer, W/1D Z-2060BA 882-6000R9-000 engine/RS-232 DB9(F) cable / Mini USB interface WindowsCE.NET Handheld Computer, W/Wireless...
  • Page 55 8 RTS (Request to send) 10 GND(Signal ground) 9 RI (Ring indicator) RJ45 USB type B cable connect from 173-0U3000-150 USB Cable CRD-60 to PC USB port. Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 55 / 58...
  • Page 56 ZEBEX INDUSTRIES INC. 3. Z-2060 Series Optional Accessories Part Number Model Name Description RS-232 cable RS232 charging cable for Z-2050/2060 170-70R449-180 PIN-OUT configuration DB-9 (Female) CD (Carrier detect) TxD (Transmit data) RxD (Receive data) DSR (Data set ready) GND (Signal ground)
  • Page 57 11S-900180-008 AC adapter Australia type head ,interchangeable Adapter Head 11S-000002-008 plug, for 11S-900180-008 AC adapter Europe type head ,interchangeable Adapter Head 11S-000003-008 plug, for 11S-900180-008 AC adapter Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 57 / 58...
  • Page 58 ZEBEX INDUSTRIES INC. << MEMO >> Subject Version Date Page Z-2060 series User’s Manual 3.00 2010/1/25 58 / 58...
