Handheld Computer
Z-2060
User's Manual
series
RESET
ENT
ESC
1
abc
4
jkl
7
stu
ZEBEX INDUSTRIES INC.
WWW.ZEBEX.COM
( Version 2.00 )
SCAN
ENT
BS
F1
2
3
def
ghi
F2
5
6
mno
pqr
F3
8
9
yz
vwx
F4
0
@
SP

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Z-2060 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Zebex Z-2060 Series

Summary of Contents for Zebex Z-2060 Series

  • Page 1 Handheld Computer Z-2060 series ( Version 2.00 ) User’s Manual SCAN RESET ZEBEX INDUSTRIES INC. WWW.ZEBEX.COM...
  • Page 2 Revise the picture Purchaseable accessories Ver 2.00 2009/3/2 11,12 Adding the instruction of Using PowerPack Ver 2.00 2009/3/2 26~52 Adding the picture of How to order Ver 2.00 2009/3/2 53~56 Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 2 / 57...

  • Page 3: Table Of Contents

    Specifications ..................... 24 Using Barcode Scanner Scanning Barcodes ..................... 25 Using the Zebex PowerPack Backlight....................... 26 Calculator ......................28 File Transfer ......................29 File Transfer Operation ................30 Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 3 / 57...
  • Page 4 Launcher....................... 33 Launcher Operation ..................35 Switch ........................39 TrayScan....................... 40 Backup/Restore ....................44 Firmware Information ..................46 Shortcut Manager ....................47 How to order ......................53 Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 4 / 57...

  • Page 5: About This Manual

    ZEBEX INDUSTRIES INC. Preface About This Manual Thank you for your purchase of the ZEBEX Z-2060 series handheld computer. ZEBEX Z-2060 series product is at the forefront of handheld computer technology, and this manual will provide the necessary information on the many and varied options available to you.

  • Page 6: Copyright

    Performance or use of this product. ZEBEX Industries Inc. will be under no liability in respect of any defect arising from fair wear and tear, willful damage, negligence, abnormal working conditions, failure to follow the instructions and warnings, or misuse or alteration or repair of the products without written approval.

  • Page 7: Safety Operation

    WARNING Disassembly and Modification Never try to disassemble or modify the device in any way. All servicing should be carried out by qualified Zebex personnel or Zebex- approved engineers. Interior Parts and Components Never touch interior high voltage parts or components. Doing so creates the danger of electrical shock.

  • Page 8: Federal Communication Commission (Fcc) Statement

    End users must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 8 / 57...

  • Page 9: Unpacking Package Contents

    Mobile Data Terminal Mini USB cable Stylus Pen (Terminal to PC USB port) Sling for stylus Pen RS-232 DB9 (F) Cable Hand Strip Hand strip Holder Battery Pack Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 9 / 57...

  • Page 10: Optional Parts

    ZEBEX INDUSTRIES INC. Optional Parts Cradle package Docking Cradle RS232 cable AC Adapter USB cable (Cradle to USB) Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 10 / 57...

  • Page 11: Purchaseable Accessories

    AC Adapter Britain Plug head RS232 Cable U.S. Plug head RS-232 DB9 (F) Cable Australia Plug head USB cable (Cradle to USB) Europe Plug head Battery Pack Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 11 / 57...
  • Page 12 ZEBEX INDUSTRIES INC. Stylus Pen Sling for stylus Pen Hand Strip Hand strip Holder Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 12 / 57...

  • Page 13: General Guide

    This port is for RS-232 communication with PC Stylus pen For touch screen operation and press RESET switch. Hand strip Protects the Handheld Terminal to drop. Battery Main battery Sling for stylus pen Sling Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 13 / 57...
  • Page 14 4. Press after SF/Fn key and press F1-F4 key to perform F5 - F8 key. Tab key Press to add a tab indention. Space key Press to add a space character. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 14 / 57...

  • Page 15: Getting Start

    Inserting the Battery Insert the battery pack as shown and watch the battery direction.. Remove the Battery Push the side lock to pick up the battery pack. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 15 / 57...

  • Page 16: Charging The Battery

    Charging by cable Connect the charging cable and AC adaptor as shown. Charging by cradle AC Power USB Interface Adapter Jack In RS232/COM port Interface Cradle - rear view Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 16 / 57...

  • Page 17: Charging The Battery Separately In The Cradle

    Right LED - The LED lit when the cradle is connected to AC power. Charging the battery separately in the cradle Insert the battery into the compartment at the rear of the cradle. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 17 / 57...
  • Page 18 Connect the power jack to the cradle and plug AC adapter into the socket. NOTES When charging the battery for the first time, charge for at least 12 hours prior to use. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 18 / 57...

  • Page 19: System Reset

    Cold reset will erase ALL pre-configured data on the scanner. Check carefully to make sure you have uploaded all important files to your PC before proceeding with the reset. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 19 / 57...

  • Page 20: Pc System Requirements

    RS232/COM interface connector on the cradle and the other to the COM1 port on your PC. 1. Or can use attach one RS-232 cable to connect with your computer’s COM port directly. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 20 / 57...

  • Page 21: Connecting Via Usb Cradle

    You can connect the Z-2060 directly to your PC, without the need for the cradle, using the Mini USB cable, attaching it to the port on the left hand side of the device. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 21 / 57...

  • Page 22: Inserting Sd Card

    1. Make sure the power is turn off. 2. Open the SD Slot cover as shown, Take off the SD card. 3. Closed the SD slot cover. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 22 / 57...

  • Page 23: About The Product

    The following skills or experiences are also desirable. ● Windows CE devices ● ActiveSync ● Something networking experience. Hardware Required The following models of the ZEBEX Z-2060 series and the dedicated options are available. Available models and the features: Model name Barcode scanner Bluetooth IEEE802.11b/g...

  • Page 24: Specifications

    CE & FCC Part 15B, 15 C,CE RF,LVD,ESD Cradle Single slot USB / RS-232 charging cradle with spare battery slot Microsoft VC 6.0 development environment Software &Development Supports SDK for program development Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 24 / 57...

  • Page 25: Using Barcode Scanner Scanning Barcodes

    2. Once in the correct position, press the SCAN button. An audible alarm is heard and the barcode digits will appear on the LCD screen if the scan is successful. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 25 / 57...

  • Page 26: Using The Zebex Powerpack

    ZEBEX INDUSTRIES INC. Using the Zebex PowerPack To save your time and effort in developing applications on Z-2060, ZEBEX provides its owndesign system management tool to called “PowerPack” to let you control it directly. The PowerPack management tools install in each of our WinCE product. It is free charge for you.
  • Page 27 Always OFF: This function can set up the backlight to be always off. 3. Brightness Control Bar The brightness of the backlight can be changed via control bar. Put up to light and put down to dark. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 27 / 57...

  • Page 28: Calculator

    : Numeric key. : Division function. : Multiplication function. : Subtraction function. : Addition function. : A decimal point of dot. :To be equal to, The amount. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 28 / 57...

  • Page 29: File Transfer

    The OBEX communication protocol was a very popular protocol for Notebook PC or cell phone device. So you can very easy to send a data file from ZEBEX’s WinCE device into Notebook PC or cell phone for enhance the device File Transfer solution.

  • Page 30: File Transfer Operation

    IrDA interface, then the device will detected other one like the following picture shown. 1.2 Select the receive device and press “ ” button for start the connection or press “ ” button for stop the connection. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 30 / 57...
  • Page 31 ZEBEX INDUSTRIES INC. 1.3 Click the & buttons to choose the file to transfer. 1.4 Click the “ ” button, start the file transfer. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 31 / 57...
  • Page 32 Click the “ ” button to connect with selected device or “ ” button to stop the connection. Note: Device is no necessary being paired before connected. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 32 / 57...
  • Page 33 ZEBEX INDUSTRIES INC. 2.3 Click the & buttons to choose the file to transfer. 2.4 Click the “ ” button, start the file transfer. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 33 / 57...

  • Page 34: Launcher

    ZEBEX INDUSTRIES INC. Launcher The Launcher utility is an auto execution program for ZEBEX’s WinCE device. You may set programs into the Launcher list box and running the program by automatically or manually. 1. Selected the check box of ” will running whole programs listed in the box automatically one by one.

  • Page 35: Launcher Operation

    1.2 Select the target file. Click the “ ” button and select the program file then click “ ” button to confirmed and return back to the Launcher menu. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 35 / 57...
  • Page 36 1.3 Click " " button to add the program into list box. 2. Launch a program: Selected the program and click the " "button to execute the program. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 36 / 57...
  • Page 37 ” path. Then click “ ” button to confirm the change. 4. Remove a program: Select a program form list box and click the" "button to remove it. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 37 / 57...
  • Page 38 5. Change the running sequence of program: Select the program which is desired to rearrange its running priority sequence. Click " " or " " button to adjust the running priority sequence. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 38 / 57...

  • Page 39: Switch

    The available wireless network access point will be searching automatically when you check the “ON” selection for enable WiFi function. You can select an access point and press “Connect” button to" " with that network. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 39 / 57...
  • Page 40 You also can use " " or " " button for display more information for network setting. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 40 / 57...

  • Page 41: Trayscan

    “CR/LF” for selection. 4. Preamble Set the preamble character with barcode data. 5. Setting To set the barcode parameter value of each kind of barcode for barcode scanner. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 41 / 57...
  • Page 42 " button to setting the barcode parameter value of each kind of barcode. Press " "button to use system default value to set up the barcode parameter. The default value was show in below pictures. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 42 / 57...
  • Page 43 ZEBEX INDUSTRIES INC. The default values of EAN/UPC code and Code39. The default values of ITF 2 of 5 code and Code128. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 43 / 57...

  • Page 44: Backup/Restore

    You can find this application is located on path “\settings\control Panel\”. There is a pop-up warming message advice you close all application and stop running any program when you start the application. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 44 / 57...
  • Page 45 To click " " button go to the Backup / Restore menu. If has already inserted mini-SD you can press " " button, begin to Backup or Restore. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 45 / 57...

  • Page 46: Firmware Information

    This information is good for identify device firmware version for future update or maintenance. Click the Device frame to shows the Model number. and double-chick it will return to display the Device ID. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 46 / 57...

  • Page 47: Shortcut Manager

    Turn the screen backlight to bright. F3 & F7: Panel Darker Turn the screen backlight to dark. : Calculator Start the Calculator program. : CaIibrate Stylus Start the screen Calibration function. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 47 / 57...
  • Page 48 “SF/Fn” button first then press F1 to assign it. It’s mean F5~F8 function key is compose of “SF/Fn” with F1~F4. SF/Fn + F1 = F5, SF/Fn + F2 = F6, SF/Fn + F3 = F7, SF/Fn + F4 = F8 Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 48 / 57...
  • Page 49 (4) Windows Shortcuts (the swift key of WinCE system function) (5) IE Shortcuts (the swift key of IE) Defines the standard function by deferent the “ ” 3. Function : being selected. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 49 / 57...
  • Page 50 4. Specified Application: Setting others application program on the device for the assigned function key. After select this function, then press " " button to assign an application for this function key. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 50 / 57...
  • Page 51 ” button after you selected an application of the shortcut for a function key. The screen will change to the page of “ ” and update the function key setting information. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 51 / 57...
  • Page 52 Cancel the function key setting. Cancel : Press “ “ “ button to cancel the current function key setting and back to the original display of page “ ”. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 52 / 57...

  • Page 53: How To Order

    ZEBEX INDUSTRIES INC. How to order Please offer Part Number or Model Name for next purchase. 1. Z-2060 Series Windows CE.NET Handheld Computer Set. Part Number Model Name Description Windows CE.NET Handheld Computer, W/1D Z-2060BA 882-6000R9-000 engine/RS-232 DB9(F) cable / Mini USB interface WindowsCE.NET Handheld Computer, W/Wireless...
  • Page 54 8 RTS (Request to send) 10 GND(Signal ground) 9 RI (Ring indicator) RJ45 USB type B cable connect from 173-0U3000-150 USB Cable CRD-60 to PC USB port. Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 54 / 57...
  • Page 55 ZEBEX INDUSTRIES INC. 3. Z-2060 Series Optional Accessories Part Number Model Name Description RS-232 cable RS232 charging cable for Z-2050/2060 170-70R449-180 PIN-OUT configuration DB-9 (Female) CD (Carrier detect) TxD (Transmit data) RxD (Receive data) DSR (Data set ready) GND (Signal ground)
  • Page 56 11S-900180-008 AC adapter Australia type head ,interchangeable Adapter Head 11S-000002-008 plug, for 11S-900180-008 AC adapter Europe type head ,interchangeable Adapter Head 11S-000003-008 plug, for 11S-900180-008 AC adapter Subject Version Date Page Z-2060 series User’s Manual 2.00 2009/3/2 56 / 57...
