  • Page 1 720P IR Dome PoE IP Camera ICA-4150 720P IR Dome PoE IP Camera ICA-4150...
  • Page 2 Further, PLANET reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation to notify any person of such revision or changes.
  • Page 3 Do not dispose of WEEE as unsorted municipal waste and have to collect such WEEE separately. Revision User’s Manual of PLANET 720P IR Dome PoE IP Camera Model: ICA-4150 Rev: 1.1 (May, 2015) Part No. EM-ICA-4150_v1.1...

  • Page 4: Table Of Contents

    1.3 Features....................8 1.4 Product Specifications.................9 Chapter 2. Hardware Interface..............11 2.1 Physical Descriptions................ 11 2.1.1 Identification of ICA-4150 Physical Details ......11 2.1.2 I/O Control Instruction............. 11 2.2 Hardware Installation ................ 12 2.3 Initial Utility Installation..............12 2.4 Setup ActiveX to use the Internet Camera ........18 2.4.1 Internet Explorer 6 for Windows XP........18...
  • Page 5 720P IR Dome PoE IP Camera ICA-4150 Appendix D: Configuring Port Forwarding Manually ........41 Appendix E: Power Line Frequency.............. 43 Appendix F: Troubleshooting & Frequently Asked Questions....... 44 - 5 -...

  • Page 6: Chapter 1. Product Introduction

    1.2 Overview Compact and Cost-effective 720p Outdoor Surveillance PLANET ICA-4150 PoE IP Camera provides high-resolution images for the round-the-clock surveillance over IP networks. It supports H.264 compression format and delivers excellent picture quality in 720p HD resolutions at 30 frames per second (fps). Its outdoor and handy features enable you to easily install the camera in any public areas, such as buildings, gardens, parking areas, markets, balconies, railway stations and hospitals.
  • Page 7 Together with powerful image processing attributes like Wide Dynamic Range and Dimensional Noise Reduction technology, the ICA-4150 is able to filter the intense backlight surrounding a subject and remove noises from video signal. Thus, the ICA-4150 offers an extremely sharp and clear image quality even under any challenging lighting conditions.

  • Page 8: Features

    PoE injector. It thus eliminates the need for extra power cables and reduces installation costs while increases the deployment flexibility. The ICA-4150 is ONVIF compliant and interoperable with other brands in the market. The ICA-4150 is indisputably the ideal choice for reliable and high performance surveillance.

  • Page 9: Product Specifications

    720P IR Dome PoE IP Camera ICA-4150 Max. resolution of 720p at 30fps DNR to improve picture quality at low lux WDR Enhancement function strengthens visibility under extremely bright or dark environments Network and Configuration Compliant with IEEE 802.3af PoE interface for flexible deployment RTSP / FTP / HTTPS protocols selectable Easy Installation &...
  • Page 10 720P IR Dome PoE IP Camera ICA-4150 Application Programming ONVIF Compliant Interface Alarm Triggering Motion detection File upload via FTP Alarm Events Notification via email, HTTP and TCP General 12V DC, 6W max. Power Requirements IEEE 802.3af Class 3 Power Consumption 6.5W max.

  • Page 11: Chapter 2. Hardware Interface

    720P IR Dome PoE IP Camera ICA-4150 Chapter 2. Hardware Interface 2.1 Physical Descriptions 2.1.1 Identification of ICA-4150 Physical Details Real Panel Item Description Lens Keep the lens clean for an excellent video quality. IR LED Emits infrared light to provide light source in dark places Detects the illumination level or the place where this IP camera is installed, and switches IR LEDs on when it’s required.

  • Page 12: Hardware Installation

    This chapter shows how to quickly set up your IP camera. The camera is with the default settings. However to help you find the networked camera quickly, the windows utility PLANET IP Wizard II can search the cameras in the network that can help you to configure some basic settings before you start advanced management and monitoring.
  • Page 13 720P IR Dome PoE IP Camera ICA-4150 3. The “Welcome to the Install Shield Wizard for PLANET IP Wizard II” prompt will display on the screen and click “Next” to continue. 4. Please click “Next” to install with original settings, or you may click “Change…” button to modify the install folder and then press “Next”...
  • Page 14 720P IR Dome PoE IP Camera ICA-4150 5. Please click “Install” to start the installation. Please click “Finish” to complete the installation and launch program immediately. - 14 -...
  • Page 15 A quick way to access IP camera is to left-click the mouse twice on a selected IP camera listed on “Device list” of PLANET IP Finder II. A login window of IE browser will be opened. - 15 -...
  • Page 16 720P IR Dome PoE IP Camera ICA-4150 Network If user wants to set a specific IP address of device, please refer to the following steps to set. Step 1. Select an IP cam from the device list Step 2. Set IP address Step 3.
  • Page 17 720P IR Dome PoE IP Camera ICA-4150 If user wants to set device as DHCP client, please refer to the following steps to set. Step 1. Select an IP cam from the device list Step 2. Check the “Enable DHCP” box Step 3.

  • Page 18: Setup Activex To Use The Internet Camera

    720P IR Dome PoE IP Camera ICA-4150 Remote Update Device Update: User could update firmware by the function. Please select a device and click “Select File” to select correct firmware, and then click ”Start Update” to start to update firmware.

  • Page 19: Internet Explorer 7 For Windows Xp

    720P IR Dome PoE IP Camera ICA-4150 Set the first 3 items • Download the signed ActiveX controls • Download the unsigned ActiveX controls • Initialize and script the ActiveX controls not marked as safe to Prompt By now, you have finished your entire PC configuration for Internet camera.

  • Page 20: Internet Explorer 7 For Windows Vista

    720P IR Dome PoE IP Camera ICA-4150 • Automatic prompting for ActiveX controls By now, you have finished your entire PC configuration for Internet camera. 2.4.3 Internet Explorer 7 for Windows Vista From your IE browser ”Tools” ”Internet Options…” ”Security”...
  • Page 21 720P IR Dome PoE IP Camera ICA-4150 • Prompt “Initialize and script active controls not marked….” By now, you have finished your entire PC configuration for Internet camera. - 21 -...

  • Page 22: Chapter 3. Web-Based Management

    720P IR Dome PoE IP Camera ICA-4150 Chapter 3. Web-based Management This chapter provides setup details of the Internet camera’s Web-based Interface. 3.1 Introduction The Internet camera can be configured with your Web browser. Before configuring, please make sure your PC is under the same IP segment with Internet camera.
  • Page 23 720P IR Dome PoE IP Camera ICA-4150 After logging on, you should see the following messages at the top of Internet Explorer: Click on the message and click Run Add-on When you see this message, click Run to install the required ActiveX control.

  • Page 24: Live View

    720P IR Dome PoE IP Camera ICA-4150 3.3 Live View Start-up screen will be as follows whether you are an ordinary user or an administrator. Streaming type Fluent or Real time Streaming type Set up the real time view stream type (Main stream/Sub stream).

  • Page 25: Video Setting

    720P IR Dome PoE IP Camera ICA-4150 3.4.1 Video Setting Video Format Video codec of the selected profile. Main stream 1280x720, 720x576, 640x480 Resolution Sub stream 720x576, 640x480, 352x288, 320x240, 174x144 Defines the targeted frame rate of this profile. For example, set...

  • Page 26: Camera Setting

    720P IR Dome PoE IP Camera ICA-4150 3.4.2 Camera Setting Brightness Large value will brighten camera. Contrast Large value will contrast camera heavily. Saturation Large value will color camera heavily. Three mode selectable Auto/Day/Night. Under Auto mode, the Day/Night Mode camera will change the image quality automatically, based on the light condition.

  • Page 27: Osd & Mask Settings

    720P IR Dome PoE IP Camera ICA-4150 3.4.3 OSD & Mask Settings OSD Settings Display region of Device Title & Time can be settable. Click “Video Mask Settings” enter to the main interface as below Select one region on the image, click “Set” to save this setup.

  • Page 28: Tcp/Ip Setting

    720P IR Dome PoE IP Camera ICA-4150 3.5.1 TCP/IP Setting This section provides the menu of connecting the device through Ethernet cable. Display the Ethernet MAC address of the device. Note that user MAC Address cannot change it. Enable this checked box when a DHCP server is installed on the network to issue IP address assignment.

  • Page 29: Port Management

    720P IR Dome PoE IP Camera ICA-4150 When you send email or position a browser to an Internet domain Preferred DNS such as xxxxx.com, the domain name system translates the names Server into IP addresses. The term refers to two things: the conventions for naming hosts and the way the names are control across the Internet.
  • Page 30 720P IR Dome PoE IP Camera ICA-4150 The procedures are: • Connect to a LAN by DHCP or Fixed IP • Access the device by entering Setting Network PPPoE as shown below: PPPoE Dial-up To enable or disable the PPPoE service here.

  • Page 31: Ftp Setting

    720P IR Dome PoE IP Camera ICA-4150 The Internet uses DNS servers to look up domain names and translates them into IP addresses. Domain names are just easy to remember aliases for IP addresses. A dynamic DNS service is unique because it provides a means of updating your IP address so that your listing will remain current when your IP address changes.

  • Page 32: E-Mail Setting

    720P IR Dome PoE IP Camera ICA-4150 3.5.5 E-mail Setting User may set up SMTP mail parameters for further operation of Event Schedule. If users want to send the alarm message out, it will need to configure parameters here and also add at least one event schedule to enable event triggering.

  • Page 33: Motion Detection

    720P IR Dome PoE IP Camera ICA-4150 Displays the date and time of the device. Device Time Synchronize with PC: Setting Click this option to enable time synchronization with PC time. Manual Setting: Click this option to set time and date manually.

  • Page 34: User Management

    720P IR Dome PoE IP Camera ICA-4150 Click “ Motion detection area” to select the motion area Select one region on the image; click “Set” to save this setup. Motion Detection Area Click “Query＂ to check the selected masking region;...

  • Page 35: System Update

    720P IR Dome PoE IP Camera ICA-4150 3.7.1 System Update To update the firmware online, click “Select file…” to select the firmware. Then click “Upgrade” to proceed. 3.7.2 Reboot System The device is restarted without changing any of the settings.

  • Page 36: Version Info

    720P IR Dome PoE IP Camera ICA-4150 3.7.5 Version Info This information shows the software version in the device. 3.7.6 Log Management User can check the system log, alarm log, operate log information of the device. 3.7.7 Local Setting Click Browse to enable you to select the save path and file name prefix, and then click OK to continue.

  • Page 37: Alarm Events

    720P IR Dome PoE IP Camera ICA-4150 3.8 Alarm Events This information shows the alarm message in the device. - 37 -...

  • Page 38: Appendix A: Ping Ip Address

    720P IR Dome PoE IP Camera ICA-4150 Appendix A: Ping IP Address The ping (or Packet Internet Groper) command is used to detect whether a specific IP address is accessible by sending a packet to the specific address and waiting for a reply. It’s also a very useful tool to confirm whether Internet camera is installed or not, or if the IP address conflicts with any other device over the network.

  • Page 39: Appendix B: Bandwidth And Video Size Estimation

    720P IR Dome PoE IP Camera ICA-4150 Appendix B: Bandwidth and Video Size Estimation The frame rate of video transmitted from the device depends on connection bandwidth between client and server, video resolution, codec type, and quality setting of server. Here is a guideline to help you roughly estimate the bandwidth requirements from your device.

  • Page 40: Appendix C: Ddns Application

    720P IR Dome PoE IP Camera ICA-4150 Appendix C: DDNS Application Configuring PLANET DDNS steps: Step 1: Visit DDNS provider’s web site and register an account if you do not have one yet. For example: Register an account at http://planetddns.com Step 2: Enable DDNS option through accessing web page of the camera.
  • Page 41 Manually set up the device with a fixed IP address, for example, 192.168.0.100. 2. Access the Router with your Web browser The following steps generally apply to any router that you have on your network. PLANET WNRT-620 is used as an example to clarify the configuration process. Configure the initial settings of the router by following the steps outlined in the router’s Quick Installation Guide.
  • Page 42 720P IR Dome PoE IP Camera ICA-4150 over the Internet. Therefore, these ports need to be made accessible over the Internet. This is accomplished using the Virtual Server function on the router. The Virtual Server ports used by the camera must be opened through the router for remote access to your camera.

  • Page 43: Appendix E: Power Line Frequency

    720P IR Dome PoE IP Camera ICA-4150 Appendix E: Power Line Frequency COUNTRY VOLTAGE FREQUENCY COMMENTS *Neutral and line wires are reversed from that Argentina 220V 50 Hz used in Australia and elsewhere. *Outlets typically controlled by adjacent switch. Australia...

  • Page 44: Frequently Asked Questions

    Do not connect device over a router. PLANET IP Finder II program cannot detect device over a router. If IP address is not assigned to the PC running PLANET IP Finder II program, then PLANET IP Finder II program cannot find device.
  • Page 45 720P IR Dome PoE IP Camera ICA-4150 Microsoft’s Internet Explorer from the Microsoft webpage. PLANET IP Finder II program fails Network may have trouble. Confirm the parameters and connections to save the network parameters. of the device. Accessing this device...
  • Page 46 720P IR Dome PoE IP Camera ICA-4150 following message: “Your current allow downloading and scripting of ActiveX controls. security settings prohibit downloading ActiveX controls”. The device work locally but not Might be caused from the firewall protection. Check the Internet externally.
  • Page 47 EC Declaration of Conformity For the following equipment: *Type of Product: 720p PoE IP Camera ICA-3150 / ICA-4150 *Model Number: * Produced by: Manufacturer‘s Name : Planet Technology Corp. Manufacturer‘s Address : 10F., No.96, Minquan Rd., Xindian Dist., New Taipei City 231,. Taiwan (R.O.C.)
