The QD-52 system consists of a CD reader, CD Writer and Controller module.
The master discs always go into the TOP CD Reader drive.
The blank CD media will always go into the BOTTOM CD Recorder drive.
The power switch and power LED are also located on the front of the QD-52 duplicator.
The LCD display will show the different menu selections and also information pertaining to the
recording process. Here is a typical example of what is displayed during the COPY process:
Displays the function being performed,
such as Copying or Testing, and shows
the record speed.
Copying – 52x
150.4 MB
Displays the amount of data left to be
recorded. This number starts at the capacity
of the master and counts down.
Shows the percentage
completed for this action.
17%
01:15
Shows the time remaining to
complete this action.
number also counts down.
