Basic Instructions
Buttons and LCD
There are four buttons and an LCD on the front panel of the QD-52 duplicator.
LED display:
Shows the menu items and any status messages that may come up during
operation.
ENT button: The ENT button, used to start a duplication process or enter into an area in the
menu structure.
ESC button: The ESC button, used to stop an operation or move up the menu structure.
▲ button, used to scroll up in the different menus.
▼ button, used to scroll down in the different menus.
Hardware Description
Power LED
Controller Interface
Reader Drive
Recorder Drive
Power Switch
6
