DSR DVD Premium Pro Series
Rack Mount
Users Guide
www.microboards.com
Version 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Premium Pro Series and is the answer not in the manual?

Questions and answers

Summary of Contents for MicroBoards Technology Premium Pro Series

  • Page 1 DSR DVD Premium Pro Series Rack Mount Users Guide www.microboards.com Version 1.0...
  • Page 2: Table Of Contents

    DSR DVD Premium Pro Rack Mount Series MICROBOARDS TECHNOLOGY, LLC TABLE OF CONTENTS System Overview ........................ 3 Unpacking your system....................... 3 Installation Requirements ....................4 Menu Overview ........................5 Setup Menu ......................... 7 Copy DVD to DVD ......................8 Simulation DVD to DVD....................8 Registering Data to the Hard Drive (HDD) ................
  • Page 3: System Overview

    MICROBOARDS TECHNOLOGY, LLC System Overview The DVD market has grown at an incredible pace and Microboards Technology has developed a duplicator with leading-edge technology to meet the growing market requirements. The DSR DVD Premium Pro Series is the first stand-alone, multi-drive DVD-+R/CD-R duplicator employing the use of General Purpose DVD-+R recorders.
  • Page 4: Installation Requirements

    DSR DVD Premium Pro Rack Mount Series MICROBOARDS TECHNOLOGY, LLC Installation Requirements System Setup • Connect the power cable to the DSR DVD Rack Mount duplicator and plug in to a protected power outlet strip or UPS power supply. •...
  • Page 5: Menu Overview

    DSR DVD Premium Pro Rack Mount Series MICROBOARDS TECHNOLOGY, LLC Menu Overview COPY START? INSERT INSERT ANALYZING MASTER COPY 15:26 MASTER DISC TARGET DISC CD-DA (DISCtoDISC) INSERT ANALYZING MASTER COPY 15:26 COPY CD+G START? INSERT CD+G (DISCtoDISC) MASTER DISC TARGET DISC MASTER SELECT? >READER?
  • Page 6 DSR DVD Premium Pro Rack Mount Series MICROBOARDS TECHNOLOGY, LLC Important Notes: * There are 10 hard drive partitions available for storing DVD and/or CD masters. * The Master Clear? menu item will only appear if information has been stored on the internal hard drive.
  • Page 7: Setup Menu

    DSR DVD Premium Pro Rack Mount Series MICROBOARDS TECHNOLOGY, LLC Setup Menu...
  • Page 8: Copy Dvd To Dvd

    DSR DVD Premium Pro Rack Mount Series MICROBOARDS TECHNOLOGY, LLC Copy DVD to DVD 1. Place the Master Disc into the Reader drive 2. Place the blank DVD-+R(/W) disc(s) into the Recorder drive(s) 3. The display reads COPY START? (DISC to DISC)
  • Page 9: Registering Data To The Hard Drive (Hdd)

    DSR DVD Premium Pro Rack Mount Series MICROBOARDS TECHNOLOGY, LLC Registering Data to the Hard Drive (HDD) When registering data to a partition on the internal hard drive, you do have the option of recording to the blank media as well. In the SETUP menu, go to “Copy DISC to HD/DISC”...
  • Page 10: Erasing Dvd-+Rw Media

    DSR DVD Premium Pro Rack Mount Series MICROBOARDS TECHNOLOGY, LLC Erasing DVD-+RW media 1. At the COPY START? (DISC to DISC) menu, press the NO key until the display shows DISC ERASE? (REWRITABLE): DISC ERASE? (REWRITABLE) 2. Load the Recorder(s) with the DVD-+RW media you wish to erase. You can erase one disc at a time or fill all the Recorders to erase multiple discs at once.
  • Page 11: Clearing The Hard Drive (Hdd)

    DSR DVD Premium Pro Rack Mount Series MICROBOARDS TECHNOLOGY, LLC COPY START? (HDD1 to DISC) 7. If you wish to select a different hard drive partition, press the NO key in step 5, unit the display shows the partition you wish to copy.
  • Page 12 DSR DVD Premium Pro Rack Mount Series MICROBOARDS TECHNOLOGY, LLC 7. Press the Yes button if you are sure you want to clear the HDD. 8. The hard drive will now be cleared and you will be asked if you want to register another master to the HDD.
  • Page 13: Copy Cd To Cd

    DSR DVD Premium Pro Rack Mount Series MICROBOARDS TECHNOLOGY, LLC Copy CD to CD 1. Place the Master Disc into the Reader drive 2. Place the blank CD-R(/W) disc(s) into the Recorder drive(s) 3. The display reads COPY START? (DISC to DISC)
  • Page 14: Registering Data To The Hard Drive (Hdd)

    DSR DVD Premium Pro Rack Mount Series MICROBOARDS TECHNOLOGY, LLC Registering Data to the Hard Drive (HDD) When registering data to a partition on the internal hard drive, you do have the option of recording to the blank media as well. In the SETUP menu, go to “Copy DISC to HD/DISC”...
  • Page 15: Erasing Cd-Rw Media

    DSR DVD Premium Pro Rack Mount Series MICROBOARDS TECHNOLOGY, LLC Erasing CD-RW media 1. At the COPY START? (DISC to DISC) menu, press the NO key until the display shows DISC ERASE? (REWRITABLE): DISC ERASE? (REWRITABLE) 2. Load the Recorder(s) with the CD-RW media you wish to erase. You can erase one disc at a time or fill all the Recorders to erase multiple discs at once.
  • Page 16: Clearing The Hard Drive (Hdd)

    DSR DVD Premium Pro Rack Mount Series MICROBOARDS TECHNOLOGY, LLC 7. If you wish to select a different hard drive partition, press the NO key in step 5, unit the display shows the partition you wish to copy. 8. Place the blank CD-R disc(s) into the Recorder(s) and wait 10 seconds for the light(s) on the front of the Recorder(s) to stop blinking.
  • Page 17: Track Extraction

    DSR DVD Premium Pro Rack Mount Series MICROBOARDS TECHNOLOGY, LLC 9. Press Yes and the Reader drive will eject and you can insert another master to register to the HDD. REGIST 600MB CDROM 10. Press NO and you can exit this menu.
  • Page 18: Error Status In Track Extraction

    DSR DVD Premium Pro Rack Mount Series MICROBOARDS TECHNOLOGY, LLC 5. If you skip forward all tracks, it asks if you want to end extraction for the master data. EXTRACT THE Trk? 1/12 EXTRACTION? Press “YES” to finish extraction and register selected tracks in HDD.
  • Page 19: Setup Menu

    DSR DVD Premium Pro Rack Mount Series MICROBOARDS TECHNOLOGY, LLC Setup Menu 1. At the COPY START? (DISC to DISC) menu, press the NO key until the display shows SETUP? (MODE CHANGE) SETUP? (MODE CHANGE) 2. Press the Yes button 3.
  • Page 20: Session Mode

    DSR DVD Premium Pro Rack Mount Series MICROBOARDS TECHNOLOGY, LLC Session Mode: For CD only. Invalid for DVD. Select either from AUTO, CLOSE, or OPEN. AUTO: Make the session of copied disc as same as the master. CLOSE: Close the session of copied disc.
  • Page 21: Error Codes

    DSR DVD Premium Pro Rack Mount Series MICROBOARDS TECHNOLOGY, LLC Error Codes Read ASCQ Description NO ADDITIONAL SENSE INFORMATION I/O PROCESS TERMINATED, PLAY OPERATION ABORTED AUDIO PLAY OPERATION IN PROGRESS AUDIO PLAY OPERATION PAUSE AUDIO PLAY OPERATION SUCCESSFULLY COMPLETED AUDIO PLAY OPERATION STOPPED DUE TO ERROR...
  • Page 22 DSR DVD Premium Pro Rack Mount Series MICROBOARDS TECHNOLOGY, LLC RECOVERED DATA WITH NEGATIVE HEAD OFFSET RECOVERED DATA WITH RETIES AND/OR CIRC APPLIED RECOVERED DATA USING PREVIOUS SECTOR ID RECOVERED DATA WITH ERROR CORRECTION APPLIED RECOVERED DATA WITH ERROR CORP. & RETRIES APPLIED...
  • Page 23 DSR DVD Premium Pro Rack Mount Series MICROBOARDS TECHNOLOGY, LLC MECHANICAL POSITIONING OR CHANGER ERROR INVALID BITS IN IDENTIFY MESSAGE LOGICAL UNIT HAS NOT SELF-CONFIGURED YET LOGOCAL UNIT FAILURE TIMEOUT ON LOGICAL UNIT TARGET OPERATING CONDITIONS HAVE CHANGED MICROCODE HAS BEEN CHANGED...
  • Page 24 DSR DVD Premium Pro Rack Mount Series MICROBOARDS TECHNOLOGY, LLC Write ASCQ Description NO ADDITIONAL SENSE INFORMATION I/O PROCESS TERMINATED, PLAY OPERATION ABORTED AUDIO PLAY OPERATION IN PROGRESS AUDIO PLAY OPERATION PAUSED AUDIO PLAY OPERATION SUCCESSFULLY AUDIO PLAY OPERATION STOPPED DUE TO ERRPOR...
  • Page 25 DSR DVD Premium Pro Rack Mount Series MICROBOARDS TECHNOLOGY, LLC RECOVERED DATA WITH RETRIES AND/OR CIRC APPLIED RECOVERED DATA USING PREVIOUS SECTOR ID RECOVERED DATA WITHOUT ECC - DATA AUTO-REALLOCATED RECOVERED DATA WITHOUT ECC - RECOMMEND REASSIGNMENT RECOVERED DATA WITHOUT ECC - RECOMMEND REWRITE...
  • Page 26 DSR DVD Premium Pro Rack Mount Series MICROBOARDS TECHNOLOGY, LLC COPY CANNOT EXECUSE SINCE HOST CANNOT DISCONNECT COMMAND SEQUENCE ERROR NOT READY TO READY CHANGE, MEDIUM MAY HAVE CHANGED POWER ON, RESET, OR BUS DEVICE RESET OCCURRED PARAMETERS CHANGED MODE PARAMETERS CHANGED...
  • Page 27 DSR DVD Premium Pro Rack Mount Series MICROBOARDS TECHNOLOGY, LLC TAGGED OVERLAPPED COMMANDS (NN=QUEUE TAG) OVAERLAPPED COMMANDS ATTEMPTED ERASE FAILURE ERASE FAILURE - Incomplete erase operation detected MEDIA LOAD OR EJECT FAILED MEDIUM REMOVAL PREVENTED SYSTEM RESOURCE FAILURE UNABLE TO RECOVER TABLE-OF-CONTENTS...
  • Page 28: Specifications

    • The DSR DVD Standard Pro Series tower will now reboot and be ready for use with the new firmware program running. Contact Information For technical questions or support issues, please contact Microboards Technology technical support at PH: 952-556-1639, FAX: 952-556-1628, by email at support@microboards.com...
