Orbit II Disc Copier Reference Manual – Revision K

5.3 Installing the Orbit II (cont)

Place the Orbit II Disc Copier on the work space with its back panel accessible to you:

Make sure the switch on the external Power Supply is OFF

Insert the DC output connector of the external Power Supply in the rear panel DC receptacle

Connect the external Power Supply to an AC Receptacle, but do not turn it on yet.

Rotate the assembled Orbit II Copy System so its control panel is facing you, and position the Power

Supply as shown in the photograph below.
