Orbit II Disc Copier Reference Manual – Revision K

5.3 Installing the Orbit II

Prepare a properly sized workspace. Make sure you have cleared the area where your Orbit II Disc

Copier will be located. We recommend a desktop height surface, in an office-like environment, at least

36 inches wide and 18 inches deep. This will allow space on each side of the unit for blank media,

masters, rejects, and processed discs. There should be at least 24 inches of clearance above the

work surface.

24 inches

36 inches

15 inches
