3MUR52XXD Series Fan
UL Model No. : AC-552
ALTO
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Monte Carlo Fan Company 3MUR52XXD Series
Summary of Contents for Monte Carlo Fan Company 3MUR52XXD Series
- Page 1 3MUR52XXD Series Fan UL Model No. : AC-552 MonteCarloFans.com To register your fixture, please visit our website: MonteCarloFans.com NEED HELP? STOP ALTO ¿NECESITA AYUDA? AVEZ-VOUS BESOIN D’AIDE? Please do not return this product to the store. Por favor no devulva este producto a la tienda.
-
Page 2: Safety Instructions
Helpful Tools Safety instructions WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: READ AND SAVE THESE INSTRUCTIONS Installation work and electrical wiring must be done by qualified person(s) in accordance with applicable codes and standards (ANSI/NFPA 70-1999), including fire-rated construction. - Page 3 P l a c e c a n o p y r i n g o v e r Insert downrod into the yoke on top Thread the leadwires and of fan body. Align the hole in the downrod then place yoke s a f e ty c a b l e t h r o u g h t h e downrod with the hole in the yoke.
-
Page 4: Safety Cable Installation
Flushmount Installation Go to step 31 to finish installation Lift Conopy allowing the 2 studs to Remove side covers from canopy protrude through the canopy. Remove set screws and pins from Next lift the cover ring and install yoke as shown in inset. knurled nuts as shown. - Page 5 L i f t f a n t o m o u n t i n g b r a c k e t , aligning the “L” shape holes with the Install blade bracket with blade by 3 Install the blade assembly to motor screws on the mounting bracket.
- Page 6 WALL MOUNT INSTALL Re v e r s e switch Reverse feature of this fan is controlled by a switch located on top of the fan body. Turn off the fan and wait until fan blades come to stop. Setting the reverse Attach front cover to wall control Install wall control unit to outlet box switch in the left hand side will result in...
- Page 7 Remote Control Transmitter Features: MEDIUM SPEED LED LIGHT LOW SPEED HIGH SPEED LIGHT ON/OFF SETTING AND DIMMER (Press and hold to dim light infinitely) F A N O F F S E T T I N G (Turns fan off only) FAN SPEED Depress “l dot”...
-
Page 8: Troubleshooting
Trouble Shooting If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart. If a problem cannot be remedied, or you are experiencing difficulty in installation, please call our Customer Service Center at the number printed on your parts list insert sheet. - Page 9 Apr.2011...
