Motor Unit Assembly Parts

5
18
6
7
8
11
KEY PART
NO.
NO.
1
41A5615
2
41C4220A
3
41B4245
4
41D181
5
4A1344
6
108D79
7
30B532
8
12A373
9
41A3150
10
41D3058
10
12
13
DESCRIPTION
Chain Spreader
Gear and sprocket assembly.
Complete with: Spring
washer, thrust washer,
retaining ring, bearing plate,
roll pins (2), drive gear and
worm gear, helical gear
w/retainer and grease
Line cord
End panel
Light socket
Lens
Capacitor - 1/2 HP
Capacitor bracket
Terminal block w/screws
Motor & bracket assembly.
Complete with: Motor, worm,
bracket, bearing assembly,
RPM sensor
1
3
2
16
9
15
14
(Down) Contact
Brown Wire
Drive
Gear
Center Limit
Contact
KEY PART
NO.
NO.
11
41A5525-5
12
41A2818
13
41D3452
14
41A2822-1
15
41C4398A
16
41AC050-1M
17
41C5497
41C5498
18
41A5484-1
41A2826
41A2825
38
17
4
LIMIT SWITCH ASSEMBLY
(Up)
Yellow Wire
Contact
DESCRIPTION
Cover
Limit switch drive & retainer
Limit switch assembly
Interrupter cup assembly
RPM sensor assembly
Receiver logic board assembly.
Complete with: Logic board
and end panel
High voltage wire harness
Low voltage wire harness
End panel
NOT SHOWN
Motor shaft bearing kit
Opener assembly hardware
kit (includes screws not
designated by a number in
illustration)
Grey Wire
