Epilson STS TM
2.1

Cabinet Placement and Environment

The complete STS system may consist of more than one cabinet depending on whether the STS is a stand-alone
unit or it is used in conjunction with input isolation or output distribution cabinets such as the Power Management
Module 2 (PMM 2 ) cabinets. Cabinets must be arranged in the required positions to ensure proper connections.
When facing the Epsilon STS™ from the front, the standard arrangement provides for any PMM
cabinets to be located on the right hand side. The PMM
interconnect cables and side barrier(s) are supplied with the PMM
supplied with the Epsilon STS™.
The Epsilon STS™ is intended for use in an environment where control of temperature and humidity is provided.
The maximum operating and recommended environmental parameters are listed in Appendix B.
The Epsilon STS™ cabinets generate heat and exhaust air through the top portion of its enclosures. Air intake is
through the lower front or bottom of the cabinet. All other auxiliary cabinets are convection cooled. To assist you
in planning for your HVAC needs, heat rejection data is provided in Table 2.1 for a worst case scenario (i.e.,
maximum rated power output).
Table 2-1: Heat Rejection Data and Rated Current.
Data
STS Module
200A
400A
600A
2.2

Clearances and FootPrint

As can be seen in the following illustration, the footprint for each cabinet is nominally 30" deep. Additionally,
adequate space must be included in the front of each cabinet (approx. 36") to allow the door of the cabinet to be
opened for service and maintenance procedures.
Figure 2-1: 200STS and 400/600A STS Cabinet Clearances.
AIR INLET
(DO NOT BLOCK)
2 — 2
2 Ultra has cabinets located on both
Rate
BTU/Hr
5,600
11,400
16,700
CEILING
12" MIN.
RECOMMENDED FOR
AIR EXHAUST
FLOOR
Installation
2 cabinet. The interconnect brackets are
AIR INTAKE
FILTER WINDOW
(DO NOT BLOCK)
2 Plus auxiliary
sides of the STS. The
CEILING
12" MIN.
RECOMMENDED FOR
AIR EXHAUST
AIR INLET
(DO NOT BLOCK)
FLOOR
86-504004-00 B03
