Qs-4 400/600A Sts Input/Output Power Connections; Step 5 Arrival Of Mge Field Engineer - MGE UPS Systems Epsilon STS 200A Installation And User Manual

Figure QS-4 400/600A STS Input/Output Power Connections.
CONTROL WIRE
PANDUIT/WIRE-WAYS
COMMUNICATION
CARDS
TB1
TERMINAL
CONTROL WIRE
PANDUIT/WIRE-WAYS
CONTROL WIRES
Step 4 Arrival of MGE Field Engineer
The MGE Field Engineer will finalize the initial Epsilon STS™ start-up. To insure a successful installation and
reliable STS service, the MGE Field Engineer will verify all of the installation connections, fusing, and then will
examine the extensive set of Epsilon STS™ personalization parameters to insure that the operation of the STS
exactly matches your installation requirements.
86-504004-00 B03
TOP ENTRY
CONDUIT PLATE
CONTROL WIRES
THREADED THROUGH
UNIT
BRACE AT
12" INTERVALS
BOTTOM ENTRY
CONDUIT PAN
