Meyer Sound Reinforcement Loudspeaker UPM-2 Specifications page 2

UPM-2 Specifications
Acoustical – UPM-2/P-2
1
Frequency Response
Half space
Free air
2
Maximum SPL
Continuous
Peak
HF Distribution Pattern (-6dB points)
Horizontal
Vertical
UPM-2 Loudspeaker
Driver Complement
Low-Frequency
High-Frequency
Passive Network
Function
Capacitor Type
Inductor Type
Nominal Impedance
Enclosure
Finish
Connector
Protective Grill
Mounting Points
Physical Dimensions
Weight
P-2 Control Electronics Unit
Input Type
Output Type
Maximum Input/Output Level 3
Unbalanced
Balanced
Hum and Noise 4
5
Dynamic Range
Sense Input
Driver Protection Circuitry
Low Frequency
High Frequency
Indicators
Sense
Limit
Power
Controls
Connectors
Balanced Input/Output
Sense Input
Power
Physical Dimensions
Weight
60-20,000 Hz +4 dB
70-20,000 Hz +4 dB
108 dB
118 dB
45 degrees
45 degrees
(2) MS-5 5-inch cone drivers, 8 ohms per driver
1" titanium dome horn driver, 8 ohms
3-way crossover and HF driver protection
Polypropylene
Ferrite core
16 ohms
0.2 cu. ft. vented, multi-ply Finnish birch
Black textured
EP 4 (EP 5, Europe only) or 3-pin XLR (male and female)
Expanded metal screen frame, vinyl damped,
charcoal-grey foam covering
3 ⁄ "-16 nut plates
8
3 1 1
6 ⁄ " W x 18 ⁄ " H x 7 ⁄ " D
4 8 8
16 lbs. (7.3 kg)
Balanced (active), 47k ohms
Push-pull (active), 200 ohms source impedance
>+20 dBu
>+26 dBu
<–90 dBV
>105 dB
10K ohms true differential
RMS Limiter
RMS and Peak Limiter
Green LED
Red LED
Green LED
Level control, AC on/off switch, Lo Cut switch
3-pin XLR (A-3)
Banana jacks
120/240V AC, 50/60 Hz (internally switchable)
3 3
19" W x 1 ⁄ " H x 7 ⁄ " D Standard rack mount
4 4
7 lbs. (3.2 kg)
Note 1:
Measured 1 meter on axis,
pink noise input, in third-
octave ISO bands.
Note 2:
"A"-weighted noise input,
loudspeaker driven by
125watt (16 ohm rating)
mono amplifier.
Note 3:
1 kHz, 10k load, < 0.1%
THD.
Note 4:
"A" weighted.
Note 5:
Noise floor to maximum
output.
