Meyer Sound DS-2 Specification Sheet

DS-2
The DS-2 is a high-power, arrayable
mid-bass unit designed to supplement
Meyer Sound MSL-3 and MSL-10A loud-
speaker systems in the 50-160 Hz range.
Optimized to perform in a wide range of
large-scale sound reinforcement applica-
tions, the DS-2 delivers high sound pres-
sure levels with extremely low distortion
and offers exceptionally controlled directiv-
ity.
The system utilizes two proprietary 15-
inch cone drivers in a folded horn enclo-
sure braced with steel vertical reinforcing
rods. The horn features a hyperbolic flare
for maximum energy transfer with mini-
mum frequency response ripple. Its bal-
anced compression chamber presents a
Mid-Bass
Loudspeaker
— 24
–
–
— 21
–
–
— 18
–
–
— 15
–
–
— 12
–
–
— 9
–
–
— 6
–
–
— 3
–
–
— 0
Inches
symmetrical load to the drivers, providing
very high power handling. The rugged,
multiple-ply hardwood cabinet is fitted
with handles and, optionally, aircraft-style
rigging pan fittings.
The DS-2 requires a high-quality profes-
sional power amplifier capable of delivering
600 watts continuously into 4 ohms with a
signal voltage gain of 10 dB (minimum) to
32 dB (maximum), and can accommodate
up to 2500 watts burst power.
Features
High power
Flat frequency response
Arrayable
Rugged
Long-term reliability
Applications
Main PA arrays
Concert reinforcement
Theater sound reinforcement
Live music clubs systems
Meyer Sound Laboratories, Inc.
2832 San Pablo Avenue
Berkeley, CA 94702
(510) 486-1166
FAX (510) 486-8356
