WARNING
CALIFORNIA PROPOSITION 65
1. Combustion by-products produced when using
this product contain chemicals known to the
State of California to cause cancer, birth defects,
or other reproductive harm.
2. This product contains chemicals, including lead
and lead compounds, known to the State of
California to cause cancer, birth defects or other
reproductive harm.
Wash your hands after handling this product.
WARNING
All surfaces can be hot during use. Use protection
as required to prevent burning.
Do not use this unit on or near combustible surfaces
or structures such as wood decks, dry leaves or
grass, vinyl or wood siding, etc.
SEE OWNERS MANUAL FOR IMPORTANT SAFETY
INFORMATION.
If you have questions or need assistance during assembly, please call
To insure your satisfaction and for follow-up service, register your grill online at www.grillregistration.com
Model Number 08301388-26
WARNING
CARBON MONOXIDE HAZARD
Burning charcoal inside can kill you. It gives off
carbon monoxide, which has no odor. NEVER burn
charcoal inside homes, vehicles or tents.
NEVER LEAVE FIRE UNATTENDED!
Do not allow small children near flame. Hot embers
can fly out in breezy conditions. Adequate fire
extinguishing material should be readily available.
CAUTION
Some parts may contain sharp edges. Wear
protective gloves if necessary.
Read and follow all safety statements, warnings,
assembly instructions and use & care directions
before attempting to assemble and cook.
Tools needed for assembly:
Adjustable Wrench (not provided)
Screwdriver (not provided)
07201396
04201101
1-800-241-7548
.
08301388-26 - 42804609 (07-16-10)
