  • Page 2: Table Of Contents

    Please register your product at : http://www.rosewill.com for complete warranty information and future support for your product. If you have any question while using our products, please visit our website : www.rosewill.com for latest driver & user manual or feel free to contact us.

  • Page 3: Disassemble Chart

    ( Please refer to your motherboard’s user manual to connect. ) USB 3.0 CONNECTOR USB2.0 CONNECTOR HD Audio CONNECTOR USB+5V USB+5V AUD GND PORT1L PRESENCE# PORT1R SENSE1 RETURN PORT2R NO PIN SENSE SEND NO PIN SENSE2 RETURN PORT2L NO PIN NO PIN © All rights reserved by Rosewill...

  • Page 4: Top I/O Function

    CASE NEUTRON User Manual Top I/O functions Fan speed Fan speed HDD dock controller controller Reset Power button button Power LED Audio USB 3.0 USB 2.0 © All rights reserved by Rosewill...

  • Page 5: Accessory Box

    FDD screw / D 4 PCS HDD screw / E 6 PCS 2.5"HDD screw / F 32 PCS M/B stand off 9 PCS Socket tool of M/B stand off 1 PCS Cable Tie 5 PCS © All rights reserved by Rosewill...

  • Page 6: Installation Guide

    CASE NEUTRON User Manual Installation Guide 1. Open Chassis 1-1 Unscrew to remove both left and right panels. 2. Install Power Supply 2-1 Take out the rear frame of PSU window. © All rights reserved by Rosewill...
  • Page 7 Secure rear frame onto PSU with Screw A. * screw A 2-3 Slide the PSU into chassis from back side and secure PSU frame back to chassis. © All rights reserved by Rosewill...

  • Page 8: Install Motherboard

    3-2 Install the CPU , CPU cooler and DRAM modules onto motherboard before install motherboard into Chassis. 3-3 Secure motherboard stand-offs on mother- board plate , to place the motherboard onto stand-offs and secure with screw B. * screw B © All rights reserved by Rosewill...
  • Page 9 CASE NERTRON User Manual 3. Install Motherboard 3-4 Secure back the Motherboard plate with complete MB set into Chassis. 3-5 Pass through the cable hole of M/B plate to connect CPU 20+4P onto motherboard. © All rights reserved by Rosewill...

  • Page 10: Install Add In Card

    CASE NERTRON User Manual 4. Install Add-on Card 4-1 Unscrew the PCI screw to remove the expansion slot cover. 4-2 Install the add-on card 4-3 Screw to secure the add-on card © All rights reserved by Rosewill...

  • Page 11: Install External 5.25" Device

    Unlatch the bay cover by pressing the hooks in and then remove. 5-2 Install devices from the front panel into the chassis and then secure with screw E. 5-3 Put the front bezel back onto chassis. © All rights reserved by Rosewill...

  • Page 12: Install 3.5"/2.5" Hdd/Ssd

    HDD tray by screw F. *Screw F 6-3 Slide the HDD tray into the HDD cage and push it until snaps into place. 6-4 Slide the HDD cage back to the chassis and then secure by screw. © All rights reserved by Rosewill...
  • Page 13 7. System ready 7-1 Double check that all connectors are solidly connected to motherboard, add-on cards and the other peripheral devices. 7-2 Close both side panels back and secure with screws 7-3 Computer system is ready. © All rights reserved by Rosewill...
  • Page 14 Pull the indicated position to directly remove the magnet front bezel filter. 9. Install optional equipment Neutron has options to install additional fans or two 240mm liquid cooling radiator. To install a liquid cooling radiator on top cover or remove existing installed 120mm fans to install a 240mm liquid cooling radiator.
