  • Page 1 CASE 422 Series USER Manual www.rosewill.com...

  • Page 2: Table Of Contents

    CASE 422 series Contents Installation 1.Opening Chassis 2.Installing Motherboard 3.Installing 5.25" Device 4.Installing 3.5" Device 5.Installing 3.5" HD 6.Installing Case Feet 7.USB port & Audio Port Information © 2004-2006 Rosewill Inc. All rights reserved by Rosewill User Manual...

  • Page 3: Opening Chassis

    CASE 422 series 1.Opening Chassis Unscrew screws on the back panel. Pull the side panel back then pull out. User Manual Pull out the front panel from the buttom. © 2004-2006 Rosewill Inc. All rights reserved by Rosewill...

  • Page 4: Installing Motherboard

    Secure the motherboard on the motherboard stand-off with screws. © 2004-2006 Rosewill Inc. All rights reserved by Rosewill User Manual...

  • Page 5: Installing 5.25" Device

    CASE 422 series 3. Installing 5.25” Device Push to remove drive cover Insert the 5.25” device into the 5.25” bay © 2004-2006 Rosewill Inc. All rights reserved by Rosewill User Manual Screw the 5.25” device in place...

  • Page 6: Installing 3.5" Device

    CASE 422 series 4. Installing 3.5” Device Push to remove drive cover Insert the 3.5” device into the 3.5” bay © 2004-2006 Rosewill Inc. All rights reserved by Rosewill User Manual Screw the 3.5” device in place...

  • Page 7: Installing 3.5" Hd

    CASE 422 series User Manual 5. Installing 3.5” HDD into the 3.5” HDD into the 3.5” HDD bay Screw the 3.5” HDD in place © 2004-2006 Rosewill Inc. All rights reserved by Rosewill...

  • Page 8: Installing Case Feet

    CASE 422 series User Manual 6. Installing case feet • Lay case down and insert case feet into the bottom © 2004-2006 Rosewill Inc. All rights reserved by Rosewill...

  • Page 9: Usb Port & Audio Port

    CASE 422 series User Manual 7. USB Port & Audio Port • Find USB and Audio cables and plug them to your motherboard. Please refer to your motherboard user manual. Audio © 2004-2006 Rosewill Inc. All rights reserved by Rosewill...

  • Page 10: Information

    Please register your product at : www.rosewill.com for complete warranty information and future support for your product. If you have any question while using our products, please visit our website : www.rosewill.com for latest driver & user manual or feel free to contact us at feedback@rosewill.com Support Phone Number: 800-575-9885 Support Email: techsupport@rosewill.com...
  • Page 11 CASE 422 series User Manual We also offer : • CASE 6AS5 • KEYBOARD RK028-SLV • ADD ON CARD RC209 • ENCLOSURE RX353-S • COOLER Z3 • MOUSE RM048 © 2004-2006 Rosewill Inc. All rights reserved by Rosewill...
