- Page 1 CASE 5600 Series USER Manual www.rosewill.com...
-
Page 2: Table Of Contents
7. Cleaning Filters-Air guide Filter 8. Cleaning Filters-Front panel Filter 9. USB port 10. IEEE1394 Port 11. Audio Port 12. System Control Connectors Information © 2004-2006 Rosewill Inc. All rights reserved by Rosewill User Manual P.10 P.11 P.13 P.13 P.14 P.15... -
Page 3: Configuration
One air fi lter on the front panel ( only in R6A34) I/O Port Bracket Supports one I/O port bracket for standard ATX M/B Megal Material 0.8 mm thickness SECC rustproof & galvanized JIS Steel © 2004-2006 Rosewill Inc. All rights reserved by Rosewill... -
Page 4: Features Descriptions
Sliding Rails for 5.25" Sliding Rails for 3.5" HDD device Screw-less Add-on Card Door opening up to 270 Easy-clean fi lter Easy-clean fi lter assembly Degree (in left side panel) (in front panel) © 2004-2006 Rosewill Inc. All rights reserved by Rosewill... - Page 5 CASE 5600 series User Manual Screw-less and lockable Adjustable air inflow Front IO Ports Convenient Accessory box left side panel © 2004-2006 Rosewill Inc. All rights reserved by Rosewill...
-
Page 6: Installation
Take off the thumb screws on the back plane Push the Key-button Roll the side cover anticlockwise to open User Manual Push hooks marked in red circle to detach the front panel from the chasis © 2004-2006 Rosewill Inc. All rights reserved by Rosewill... -
Page 7: Installing Motherboard
STAND-OFF INTO THE SPECIAL MOTHERBOARD STAND-OFF OR MOTHERBOARD INSTALLING CAN'T BE PROCESSED SUCCESSFULLY. User Manual Sit the motherboard on our special motherboard stand-off and screw in all the screws into the motherboard stand-offs. © 2004-2006 Rosewill Inc. All rights reserved by Rosewill... - Page 8 Note: Screw holes marked with "M" are motherboard stand-off positions for micro ATX motherboard. Sit the motherboard on themotherboar stand-offs and screw in all the screws into the motherboard stand-offs. © 2004-2006 Rosewill Inc. All rights reserved by Rosewill User Manual...
-
Page 9: Installing 3.5" Hdd
Insert the railed HDD into the 3.25" HDD bay and push to the buttom your HDD NOTE : Screws for HDD have no thread, no screwdriver needed when you work step 3.2 User Manual © 2004-2006 Rosewill Inc. All rights reserved by Rosewill... -
Page 10: Installing 5.25" Device
Attach rails to both sides of your 5.25" device PS: You can also fasten rails on your 5.25" device by screws Insert the railed 5.25" device into the 5.25" drive bay © 2004-2006 Rosewill Inc. All rights reserved by Rosewill User Manual... -
Page 11: Installing Add On Card
Push out to loosen add on card kit Insert your add on card into the right slot User Manual Push down add on card kit to fasten the add on card © 2004-2006 Rosewill Inc. All rights reserved by Rosewill... -
Page 12: Installing Floppy
Detach the front panel (Please refer to Step 1.4, Page 5) Unscrew the screws holding the Slide out the fl oppy cage fl oppy cage User Manual Remove the metal cover © 2004-2006 Rosewill Inc. All rights reserved by Rosewill... - Page 13 CASE 5600 series Secure the fl oppy on cage by screws Slide the fl oppy cage back Secure the fl oppy cage by screws User Manual Attach the front panel © 2004-2006 Rosewill Inc. All rights reserved by Rosewill...
-
Page 14: Cleaning Filters-Air Guide Filter
8.Cleaning Filters - Front panel Filter Push front panel hooks to detach the front panel from the chassis ( please refer to step 1.4 ) © 2004-2006 Rosewill Inc. All rights reserved by Rosewill User Manual Detach the fi lter from the front panel... -
Page 15: Usb Port
9.1 Read your motherboard’s user manual to find the pins for the USB connector. 9.2 Find the USB connector and connect it to the pins. M/B USB PINS USB+5V USB+5V USB_P5 - USB_P8 - USB_P5 + USB_P8 + © 2004-2006 Rosewill Inc. All rights reserved by Rosewill User Manual... -
Page 16: Ieee1394 Port
10.1 Read your motherboard’s user manual to find the pins for the IEEE1394 connector. 10.2 Find the IEEE1394 connector and connect it to the pins. M/B IEEE1394 PINS TPA2+ +12V TPB2 TPB2+ +12V TPA2 © 2004-2006 Rosewill Inc. All rights reserved by Rosewill User Manual... -
Page 17: Audio Port
10.1 Read your motherboard’s user manual to find the pins for the Audio connector. 10.2 Find the Audio connector and connect it to the pins. M/B Audio PINS MIC2 AGND MICPWR +5VA Line out_R Bline_out_R Line out_L Bline_out_L © 2004-2006 Rosewill Inc. All rights reserved by Rosewill User Manual... -
Page 18: System Control Connectors
The diagram is just an example. NOT every motherboard has the same layout of these system control pins. Please refer to your motherboard user’s manual to check the layout before the installation. IDE_LED RESET © 2004-2006 Rosewill Inc. All rights reserved by Rosewill User Manual... -
Page 19: Information
Please register your product at : www.rosewill.com for complete warranty information and future support for your product. If you have any question while using our products, please visit our website : www.rosewill.com for latest driver & user manual or feel free to contact us at feedback@rosewill.com Support Phone Number: 800-575-9885 Support Email: techsupport@rosewill.com... - Page 20 www.rosewill.com...
