Summary of Contents for Rosewill PRISM S
- Page 1 Gaming Case Quick User Guide...
-
Page 3: Table Of Contents
6. Care ............... 08 7. Options ............09 • Specifications Table ........... 12 Front I/O Cable Pinout ........13 Front I/O ............. 13 Thank you for purchasing a Rosewill Computer Case. Please read the instruction manual before use and retain for future reference. -
Page 4: Product Overview
Disassembly (components vary by country) Cooling Fan HDD Cage Plates Side Panel SSD/HDD Glass Panel Plate Dust Filter Cooling Fan (PRISM S-LITE provides one cooling fan) Front View Right Side View Rear View Left Side View 210 mm 475 mm... -
Page 5: Accessory Box
Gaming Case PRISM S / PRISM S-LITE Accessory Box Image Part Name Function/Component Screw-A (6-32 x 6mm) Motherboard Screw-B (6-32 x 5mm) 3.5” HDD Screw-C (M3 x 5mm) 2.5” SSD Motherboard Standoff (Pre-Installed) Standoff Installation Nut Setter (Optional: Standoffs are... -
Page 6: Installation Guide
Gaming Case PRISM S / PRISM S-LITE Installation Guide 1. Open the Unit 1-1. Loosen the thumbscrews and take off panel R and L (Figure 1). • Simply loosen screws to remove side panel... -
Page 7: Install The Power Supply
Gaming Case PRISM S / PRISM S-LITE 2. Install the Power Supply 2-1. Set the power supply unit (PSU) at the top of the case and secure with Screw-A (Figure 2). 3. Install Motherboard 3-1. Secure the motherboard down onto the pre-installed standoff with Screw-B (Figure 3). -
Page 8: Install Add-On Card
Gaming Case PRISM S / PRISM S-LITE 4. Install Add-on Card 4-1. Loosen the screws to open the cover panel/slot cover (Figure 4a). 4-2. Install the add-on card and secure with screws (Figure 4b). -
Page 9: Install 3.5"/2.5" Hdd/Sdd
Gaming Case PRISM S / PRISM S-LITE 5. Install 3.5”/2.5” HDD/SDD 5-1. Take out the 3.5”/2.5” HDD/SDD trays/plates from the chassis (Figure 5a/5b/5c). 5-2. Secure the 3.5" drive onto the tray/plate with Screw-B (Figure 5d/5e). 5-3. Secure the 2.5” drive onto the tray with Screw-C (Figure 5f/5g/5h). -
Page 10: Care
Gaming Case PRISM S / PRISM S-LITE 6. Care To prevent damage, keep all panels closed and secured. 6-1. Put the side panels back in place and secure with thumbscrews (Figure 6a). 6-2. Clean the dust filters on the bottom regularly to ensure adequate airflow (Figure 6b). -
Page 11: Options
Gaming Case PRISM S / PRISM S-LITE 7. Options 7-1. LED Light Mode (only on PRISM S) Press LED light button briefly: RGB 1 (steady-rainbow) > RGB 2 (flowing-rainbow) > RGB 3 > RGB 4 > RGB 5 (seven- color-breath) > RGB 6 (seven-color-one-way-billboard) > (seven-color-two-way-billboard) >... - Page 12 Gaming Case PRISM S / PRISM S-LITE Installing water cooling radiator on the bottom: c. Remove the bottom dust filter (Figure 7c). d. Secure the radiator with screws and put the dust filter back (Figure 7d).
- Page 13 Gaming Case PRISM S / PRISM S-LITE 7-3. GPU Card Holder PRISM S/S-LITE provides GPU card holder to prevent your GPU from bend (figure 7e/7f):...
-
Page 14: Specifications Table
Gaming Case PRISM S / PRISM S-LITE Specifications Table Model Model Name PRISM S / PRISM S-LITE Specifications Type ATX Mid Tower Color White Case Material Steel / Tempered Glass With Power Supply Power Supply Mounted Motherboard Compatibility E-ATX, ATX, Micro ATX... -
Page 15: Front I/O Cable Pinout
Gaming Case PRISM S / PRISM S-LITE Front I/O Cable Pinout USB 3.0 CONNECTOR HD Audio CONNECTOR Front I/O Mic. HD Audio USB 3.0 LED Switch or Reset Power PRISM S / PRISM S-LITE_A... - Page 16 Technical Support Information techsupport@rosewill.com 1-800-575-9885 ---------------------------------------------------------------------------------- Thank you for purchasing a quality Rosewill product. Please register your product at www.rosewill.com for complete warranty information and support for your product.
