Summary of Contents for Rosewill CULLINAN MX Series

  • Page 1 Gaming Case Series Quick User Guide...
  • Page 3: Table Of Contents

    7. Care ..............08 8. Options ............09 • Specifications Table ........... 10 Front I/O Cable Pinout ........11 Front I/O ............11 Thank you for purchasing a Rosewill Computer Case. Please read the instruction manual before using and retain for future reference.
  • Page 4: Product Overview

    Gaming Case CULLINAN MX Series Quick User Guide Product Overview Disassembly Chart (components vary by country) Right Side Panel Top Dust Filter Front Dust Filter Front Panel Bracket Left Side Panel Bracket Dimensions: 8.86" x19.00" x16.91" (W x H x D) 8.86 inches...
  • Page 5: Accessory Kit

    Gaming Case CULLINAN MX Series Quick User Guide Accessory Kit Image Part Name Function/Component Screw-A #6-32 x 6 mm Screw-B #6-32 x 6 mm Motherboard Screw-C #6-32 x 11 mm 3.5” HDD Screw-D M3 x 6.7 mm 2.5” SSD Motherboard...
  • Page 6: Installation Guide

    Gaming Case CULLINAN MX Series Quick User Guide Installation Guide 1. Open the Unit 1-1. Remove the thumb screws and take off panel R and L (Figure 1). 2. Install the Power Supply 2-1. Seat the power supply unit (PSU) at the bottom-rear of the case and secure with Screw-A...
  • Page 7: Install The Motherboard

    Gaming Case CULLINAN MX Series Quick User Guide 3. Install the Motherboard 3-1. Secure the motherboard down onto the pre-installed standoff with Screw-B (Figure 3). 4. Install Add-On Card 4-1. Loosen the thumb screws to open the cover panel. 4-2. Unscrew to release the slot cover. Install the add-on card and secure with screws.
  • Page 8: Install 3.5"/2.5" Hdd/Ssd

    Gaming Case CULLINAN MX Series Quick User Guide 5. Install 3.5"/2.5" HDD/SSD 5-1. Take out the 3.5" HDD tray from the cage/unscrew to remove the 2.5" SSD tray from the chassis. 5-2. Install the 3.5" drive onto the tool-less tray (secure with Screw-C if desired).
  • Page 9 Gaming Case CULLINAN MX Series Quick User Guide 5-4. Additional 3.5"/2.5" drives or 80 mm fans can be installed on the top/side of PSU shroud (Figure 5e). Additional fan/drive installation on the side of PSU shroud: 80 mm Fan 2.5" Drive Additional fan/drive installation on the top of PSU shroud: 3.5"...
  • Page 10: Fan Installation

    Quick User Guide 6. Fan Installation The Rosewill CULLINAN MX is equipped with a fan controller on the I/O ports to control up to 7 fans with the fan hub (Figure 6). Follow the instructions below to correctly connect the fan and controller to the fan hub.
  • Page 11: Care

    Gaming Case CULLINAN MX Series Quick User Guide 7. Care To prevent damage, keep all panels closed and secured. 7-1. Put the side panels back in place and secure with thumb screws (Figure 7). 7-2. Clean the dust filters on top/bottom regularly to ensure adequate airflow.
  • Page 12: Options

    Please refer to the Specifications Table for options. 8-2. Liquid Cooling Radiator Installation The CULLINAN MX Series supports the option of installing a max. 280 mm radiator on top or a 360 mm radiator in the front to more effectively cool high-performance systems (Figure 8).
  • Page 13: Specifications Table

    Gaming Case CULLINAN MX Series Quick User Guide Specifications Table Model Model Name CULLINAN MX Series Specs Type ATX Mid Tower Color Black Case Material Steel/Tempered Glass With Power Supply Power Supply Mounted Bottom Motherboard Compatibility ATX, Micro ATX, Mini ITX...
  • Page 14: Front I/O Cable Pinout

    Gaming Case CULLINAN MX Series Quick User Guide Features NOTICE: Please make sure your motherboard is equipped with on-board USB 3.0 socket before purchasing. • Tempered Glass Front & Side Panels • I/O Ports: 2 x USB 2.0, 2 x USB 3.0, HD Audio, Fan Speed Control •...
  • Page 15 Gaming Case CULLINAN MX Series Quick User Guide Memo...
  • Page 16 Technical Support Information techsupport@rosewill.com 1-800-575-9885 ---------------------------------------------------------------------------------- Thank you for purchasing a quality Rosewill product. Please register your product at www.rosewill.com for complete warranty information and support for your product. CULLINAN MX Series_A...
