Preface Copyright This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without written consent of the author. Version 1.0 Disclaimer The information in this document is subject to change without notice.
Declaration of Conformity This device complies with part 15 of the FCC rules. Operation is subject to the following conditions: • This device may not cause harmful interference, and • This device must accept any interference received, including interfer- ence that may cause undesired operation Canadian Department of Communications This class B digital apparatus meets all requirements of the Canadian Interference- causing Equipment Regulations.
Safety Instructions Your system is designed and tested to meet the latest standards of safety for informa- tion technology equipment. However, to ensure your safety, it is important that you read the following safety instructions. Setting up your system • Read and follow all instructions in the documentation before you oper- ate your system.
Page 5
Safety cautions and warnings Optical Drive Satety Information Optical drive sold with this system contains a CLASS 1 LASER PRODUCT. CAUTION: Invisible laser radiation when open. Do not stare into beam or view directly with optical instructions. WARNING: Makeing adjustments or performing procedures other than those speci- fied in the user’s manual may result in hazardous laser exposuer.
T T T T T ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS Preface Chapter 1 Introducing the PC Introduction..................1 Specification..................2 Front and Rear I/O................3 Packing Contents................5 7 7 7 7 7 Chapter 2 Installing the PC System Quick Installing..............7 Chapter 3...
Page 7
Chapter 4 21 21 21 21 21 Using the Software About the Software DVD-ROM/CD-ROM.........21 Auto-installing under Windows 7..........21 Running Setup..............22 Manual Installation................24 Utility Software Reference............24 Chapter 5 25 25 25 25 Trouble Shooting Start up problems during assembly..........25 Start up problems after prolong use..........26 Maintenance and care tips............26 Basic Troubleshooting Flowchart...........27...
Chapter 1 Introducing the PC Introducting Thank you for choosing 3.8L MS110 of great performance and with stylish and flexible design. Support Intel/Pineview, DC 12.5W Processor and a dimension of 270mm (H)* 205mm (D)* 70mm (W), 3.8L SFF provides the features of low power consumption (working with a 120Watt power adaptor), low noise (<26db) and space saving.
Specification Chipset ® • Intel NM10 Chipset CPU Support • Intel Pineview Dual Core 0525 (with) Memory • Support SO-DIMM DDR3*2, up to 4GB 800MHz Signle Channel SDRAM Graphics ® • Intel HD Graphics from CPU Storage • Supported 1 x 3.5” SATA II HDD •...
Front and Rear I/O Press the power button to turn the system on and off. 1. Power Button Supports SD Card/ MMC Card/ MS Card. You can eas- 2. 4 IN 1 Card ily read phone or other files on the momery card. Reader Your digital cameras, DVs, MP3 players or other digi- tal devices are highly compatible.
Page 11
6. D-SUB Connector Connecting VGA Monitor. 7. Six channel HD Microphone Jack/ Headphone Jack/ Line In Jack. Audio 8. USB Connectors Connecting USB Devices (USB2.0 Ports) 9. DC Jack It is used for power adapter 10. Antenna It is used for an optional antenna 11.
Chapter 2 Installing the PC System Quick Installation 1. Connecting VGA Monitor. (D-SUB Connector) 2. The USB connectors is for attaching USB devices, such as mouse, keyboard, printer, scanner and other USB-compatible device. 3. Connecting the Network. (LAN Connector) Installing the PC...
Page 15
4. Connecting the Microphone. (Microphone Jack) 5. Connecting Speakers or Headphones. (Headphone Jack) 6. Connecting External Audio Device. (Line In Jack) 7. Connecting Power. (DC jack) Installing the PC...
Chapter 3 Using BIOS About the Setup Utility The computer uses the latest “American Megatrends Inc. ” BIOS with support for Windows Plug and Play. The CMOS chip on the motherboard contains the ROM setup instructions for configuring the motherboard BIOS. The BIOS (Basic Input and Output System) Setup Utility displays the system’s configuration status and provides you with options to set system parameters.
Press the delete key to access the BIOS Setup Utility. CMOS Setup Utility - Copyright (C) 1985-2010, American Megatrends, Inc. Standard CMOS Setup Frequency/Voltage Control Advanced Setup Load Default Setting Advanced Chipset Setup Supervisor Password Integrated Peripherals User Password Power Management Setup Save &...
For the purpose of better product maintenance, we reserve the right to change the BIOS items presented in the manual. The BIOS setup screens shown in this chapter are for reference only. Please visit our website for updated manual. Standard CMOS Setup This option displays basic information about your system.
Type (Auto) Use this item to configure the type of the IDE device that you specify. If the feature is enabled, it will enhance hard disk performance by reading or writing more data during each transfer. PIO Mode (Auto) Use this item to set the PIO mode to enhance hard disk performance by optimizing the hard disk timing.
Page 20
Boot Up Numlock Status (On) This item defines if the keyboard Num Lock key is active when your system is started. APIC Mode (Enabled) This item allows you to enable or disable the APIC (Advanced Programmable Inter- rupt Controller) mode. APIC provides symmetric multi-processing (SMP) for sys- tems, allowing support for up to 60 processors.
Boot Other Device (Yes) When enabled, the system searches all other possible locations for an operating system if it fails to find one in the devices specified under the First, Second and Third boot devices. Press <Esc> to return to the main menu setting page. Advanced Chipset Setup This page sets up more advanced information about your system.
Integrated Peripherals This page sets up some parameters for peripheral devices connected to the system. CMOS Setup Utility - Copyright (C) 1985-2010, American Megatrends, Inc. Integrated Peripherals Help Item SATA Configuration Onboard Audio Function Enabled Options Onboard LAN Function Enabled Onboard LAN Boot ROM Disabled USB Functions...
Power Management Setup This page sets up some parameters for system power management operation. CMOS Setup Utility - Copyright (C) 1985-2010, American Megatrends, Inc. Power Management Setup Help Item ACPI Suspend Type PWRON After PWR-Fail Power Off Select the ACPI EUP Support Enabled state used for Sys-...
PC Health Status On motherboards support hardware monitoring, this item lets you monitor the parameters for critical voltages, temperatures and fan speeds. CMOS Setup Utility - Copyright (C) 1985-2010, American Megatrends, Inc. PC Health Status Help Item Smart Fan Function Enabled Shutdown Temperture Disabled...
Frequency/Voltage Control This page enables you to set the clock speed and system bus for your system. The clock speed and system bus are determined by the kind of processor you have in- stalled in your system. CMOS Setup Utility - Copyright (C) 1985-2010, American Megatrends, Inc. Frequency/Voltage Control Help Item Manufacturer...
Supervisor Password (Not Installed) This item indicates whether a supervisor password has been set. If the password has been installed, Installed displays. If not, Not Installed displays. Change Supervisor Password (Press Enter) You can select this option and press <Enter> to access the sub menu. You can use the sub menu to change the supervisor password.
Chapter 4 Using the Software About the Software DVD-ROM/CD-ROM The support software DVD-ROM/CD-ROM that is included in the motherboard package contains all the drivers and utility programs needed to properly run the bundled products. Below you can find a brief description of each software program, and the location for your motherboard version.
Drivers Tab Setup Click the Setup button to run the software installation program. Select from the menu which software you want to install. Browse CD The Browse CD button is the standard Windows command that al- lows you to open Windows Explorer and show the contents of the support disk.
Page 30
Click Next. The following screen appears: Check the box next to the items you want to install. The default options are recom- mended. Click Next run the Installation Wizard. An item installation screen appears: Follow the instructions on the screen to install the items. Drivers and software are automatically installed in sequence.
Windows 7 will appear below UAC (User Account Control) message after the system restart. You must select “Allow” to install the next driver. Continue this process to complete the drivers installation. Manual Installation Insert the disk in the DVD-ROM/CD-ROM drive and locate the PATH.DOC file in the root directory.
Chapter 5 Trouble Shooting Start up problems during assembly After assembling the PC for the first time you may experience some start up problems. Before calling for technical support or returning for warranty, this chapter may help to address some of the common questions using some basic troubleshooting tips.
c) The PC suddenly shuts down while booting up. 1. The CPU may experience overheating so it will shutdown to protect itself. Ensure the CPU fan is working properly. 2. From the BIOS setting, try to disable the Smartfan function to let the fan run at default speed.
