Summary of Contents for ECS 3.8L MS200

  • Page 2 Preface Copyright This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without written consent of the author. Version 1.0 Disclaimer The information in this document is subject to change without notice.

  • Page 3: Declaration Of Conformity

    Declaration of Conformity This device complies with part 15 of the FCC rules. Operation is subject to the following conditions: • This device may not cause harmful interference, and • This device must accept any interference received, including interfer- ence that may cause undesired operation Canadian Department of Communications This class B digital apparatus meets all requirements of the Canadian Interference- causing Equipment Regulations.

  • Page 4: Safety Instructions

    Safety Instructions Your system is designed and tested to meet the latest standards of safety for informa- tion technology equipment. However, to ensure your safety, it is important that you read the following safety instructions. Setting up your system • Read and follow all instructions in the documentation before you oper- ate your system.
  • Page 5 Safety cautions and warnings Optical Drive Satety Information Optical drive sold with this system contains a CLASS 1 LASER PRODUCT. CAUTION: Invisible laser radiation when open. Do not stare into beam or view directly with optical instructions. WARNING: Makeing adjustments or performing procedures other than those speci- fied in the user’s manual may result in hazardous laser exposuer.

  • Page 6: Table Of Contents

    T T T T T ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS Preface Chapter 1 Introducing the PC Introduction..................1 Specification..................2 Front and Rear I/O................3 Packing Contents................5 7 7 7 7 7 Chapter 2 Installing the PC System Quick Installing..............7 Chapter 3...
  • Page 7 Chapter 4 25 25 25 25 Using the Software About the Software DVD-ROM/CD-ROM.........25 Auto-installing under Windows 7..........25 Running Setup..............26 Manual Installation................28 Utility Software Reference............28...

  • Page 8: Introducing The Pc

    Chapter 1 Introducing the PC Introducting Thank you for choosing 3.8L MS200 of great performance and with stylish and flexible design. ® Support Intel Socket LGA1156 Core i3/i5 Clarkdale processors and a dimension of 270mm (H)* 205mm (D)* 70mm (W), 3.8L SFF provides the features of low power consumption (working with a 120Watt power adaptor), low noise (<30db) and space ®...

  • Page 9: Specification

    Specification Chipset ® • Intel ® CPU Support • Socket LGA1156 for Intel Core i3/i5 Clarkdale processors (up to 73W) Memory • 2 x SO-DIMM up to 8 GB Graphics ® • Built-in Intel HD graphics Storage • Supported 1 x 3.5” SATA II HDD •...

  • Page 10: Front And Rear I/O

    Front and Rear I/O Press the prower button to turn the system on and 1. Power Button off. Supports SD Card/ MMC Card/ MS Card. You can eas- 2. 4 IN 1 Card ily read phone or other files on the momery card. Reader Your digital cameras, DVs, MP3 players or other digi- tal devices are highly compatible.
  • Page 11 6. HDMI Connector Connecting HDMI Device. 7. USB Connectors Connecting USB Devices (USB2.0 Ports) 8. Eight channel HD Microphone Jack/ Headphone Jack/ Line In Jack. Audio 9. DC Jack It is used for power adapter 10. Antenna It is used for an optional antenna 11.

  • Page 12: Packing Contents

    Packing Contents Driver DVD Manual Power Stand NOTE: Please contact us immediately if any of the items is damaged or missing. Introducing the PC...
  • Page 13 Memo Introducing the PC...

  • Page 14: Installing The Pc

    Chapter 2 Installing the PC System Quick Installation 1. Connecting HDMI device. 2. Connecting VGA Monitor. (D-SUB Connector) 3. The USB connectors is for attaching USB devices, such as mouse, keyboard, printer, scanner and other USB-compatible device. Installing the PC...
  • Page 15 4. Connecting the Network. (LAN Connector) 5. Connecting the Microphone. (Microphone Jack) 6. Connecting Speakers or Headphones. (Headphone Jack) 7. Connecting External Audio Device. (Line In Jack) Installing the PC...
  • Page 16 8. Connecting Power. (DC jack) Installing the PC...
  • Page 17 Memo Installing the PC...

  • Page 18: Using Bios

    Chapter 3 Using BIOS About the Setup Utility The computer uses the latest “American Megatrends Inc. ” BIOS with support for Windows Plug and Play. The CMOS chip on the motherboard contains the ROM setup instructions for configuring the motherboard BIOS. The BIOS (Basic Input and Output System) Setup Utility displays the system’s configuration status and provides you with options to set system parameters.

  • Page 19: Using Bios

    Press the delete key to access the BIOS Setup Utility. CMOS Setup Utility - Copyright (C) 1985-2010, American Megatrends, Inc. Frequency/Voltage Control Standard CMOS Setup BIOS Security Features Advanced BIOS Features Load Default Setting Advanced Chipset Features Save & Exit Setup Integrated Peripherals Exit Without Saving Power Management Setup...

  • Page 20: Standard Cmos Setup

    For the purpose of better product maintenance, we reserve the right to change the BIOS items presented in the manual. The BIOS setup screens shown in this chapter are for reference only. Please visit our website for updated manual. Standard CMOS Setup This option displays basic information about your system.
  • Page 21 Type (Auto) Use this item to configure the type of the IDE device that you specify. If the feature is enabled, it will enhance hard disk performance by reading or writing more data during each transfer. PIO Mode (Auto) Use this item to set the PIO mode to enhance hard disk performance by optimizing the hard disk timing.

  • Page 22: Advanced Setup

    Advanced Setup This page sets up more advanced information about your system. Handle this page with caution. Any changes can affect the operation of your computer. CMOS Setup Utility - Copyright (C) 1985-2010, American Megatrends, Inc. Advanced BIOS Features Help Item Quick Boot Enabled Quiet Boot...
  • Page 23 Optical Disk Driver Priority (Press Enter) Scroll to this item and press <Enter> to view the following screen: CMOS Setup Utility - Copyright (C) 1985-2010, American Megatrends, Inc. Optical Disk Driver Priority Help Item Optical Disk Driver Specifies the boot 1st Drive CD/DVD: PM-Optiarc D sequence from the...

  • Page 24: Advanced Chipset Setup

    Advanced Chipset Setup This page sets up more advanced information about your system. Handle this page with caution. Any changes can affect the operation of your computer. CMOS Setup Utility - Copyright (C) 1985-2010, American Megatrends, Inc. Advanced Chipset Setup Help Item Intel EIST Enabled...

  • Page 25: Integrated Peripherals

    Integrated Peripherals This page sets up some parameters for peripheral devices connected to the system. CMOS Setup Utility - Copyright (C) 1985-2010, American Megatrends, Inc. Integrated Peripherals Help Item Onboard SATA Controller Enabled Onboard SATA Mode Native IDE Options Onboard USB Controller Enabled Legacy USB Support Enabled...

  • Page 26: Power Management Setup

    Power Management Setup This page sets up some parameters for system power management operation. CMOS Setup Utility - Copyright (C) 1985-2010, American Megatrends, Inc. Power Management Setup Help Item ACPI Aware O/S Suspend mode S3 (STR) Enable/Disable Deep Power Off Mode Enabled ACPI support for Power On by RTC Alarm...

  • Page 27: Pc Health Status

    PC Health Status On motherboards support hardware monitoring, this item lets you monitor the parameters for critical voltages, temperatures and fan speeds. CMOS Setup Utility - Copyright (C) 1985-2010, American Megatrends, Inc. PC Health Status Help Item CPU Temperature (PECI Mode) : System Temperature 42°C/107°F Options...

  • Page 28: Frequency/Voltage Control

    System Component Characteristics These items display the monitoring of the overall inboard hardware health events, such as System & CPU temperature, CPU & DIMM voltage, CPU & system fan speed,...etc. • CPU Temperature (PECI Mode) • System Temperature • CPU Fan1 Speed •...

  • Page 29: Bios Security Features

    Enable Clock to All PCI/PCIE (Disabled) This item displays the information of current manufacturer of the CPU installed in your computer. Ratio Actual Value: 12 This item shows the actual ratio of the CPU installed in your system. CPU Frequency Setting (533MHz) This item is used to set the CPU Frequency.

  • Page 30: Load Default Settings

    Change User Password (Press Enter) You can select this option and press <Enter> to access the sub menu. You can use the submenu to change the user password. Security Check (Setup) This item is set to enable or disable the security check. Load Default Settings This option opens a dialog box that lets you install stability-oriented defaults for all appropriate items in the Setup Utility.
  • Page 31 Memo Using BIOS...

  • Page 32: Using The Software

    Chapter 4 Using the Software About the Software DVD-ROM/CD-ROM The support software DVD-ROM/CD-ROM that is included in the motherboard package contains all the drivers and utility programs needed to properly run the bundled products. Below you can find a brief description of each software program, and the location for your motherboard version.

  • Page 33: Running Setup

    Drivers Tab Setup Click the Setup button to run the software installation program. Select from the menu which software you want to install. Browse CD The Browse CD button is the standard Windows command that al- lows you to open Windows Explorer and show the contents of the support disk.
  • Page 34 Click Next. The following screen appears: Check the box next to the items you want to install. The default options are recom- mended. Click Next run the Installation Wizard. An item installation screen appears: Follow the instructions on the screen to install the items. Drivers and software are automatically installed in sequence.

  • Page 35: Manual Installation

    Windows 7 will appear below UAC (User Account Control) message after the system restart. You must select “Allow” to install the next driver. Continue this process to complete the drivers installation. Manual Installation Insert the disk in the DVD-ROM/CD-ROM drive and locate the PATH.DOC file in the root directory.

  • Page 36: Trouble Shooting

    Chapter 5 Trouble Shooting Start up problems during assembly After assembling the PC for the first time you may experience some start up problems. Before calling for technical support or returning for warranty, this chapter may help to address some of the common questions using some basic troubleshooting tips.
  • Page 37 c) The PC suddenly shuts down while booting up. 1. The CPU may experience overheating so it will shutdown to protect itself. Ensure the CPU fan is working properly. 2. From the BIOS setting, try to disable the Smartfan function to let the fan run at default speed.
  • Page 39 Memo Trouble Shooting...
