- Page 1 INSTALLATION INSTRUCTIONS DishDrawer dishwasher DD60DA models NZ AU www.fisherpaykel.com 590664A 11.14...
- Page 3 SAfety ANd wArNiNgS wArNiNg! wArNiNg! electrical shock hazard electrical shock hazard Before installing the dishwasher, wArNiNg- improper connection remove the house fuse or open of the equipment-earthing the circuit breaker. conductor can result in a risk this appliance must be earthed. of electric shock.
-
Page 4: Important Safety Instructions
SAfety ANd wArNiNgS iMPOrtANt SAfety iNStrUCtiONS iMPOrtANt SAfety iNStrUCtiONS installation of this dishwasher requires if the dishwasher is to be relocated ● ● ● ● basic mechanical and electrical skills. from one installation to another it must Be sure to leave these instructions with be kept upright to avoid damage from ●... -
Page 5: Parts Supplied
PArtS SUPPLied Drain hose Drain hose Wire clip (2) Clamp (1) Side mounting support (1) joiner (1) (for securing (for securing bracket kit mounting Drain hose joiner) Drain hose joiner) (A and B) (2) brackets (2) OPTIONAL OPTIONAL Phillips Rubber washer Moisture protection Hexagonal Prefinished... -
Page 6: Product Dimensions
PrOdUCt diMeNSiONS Side PrOdUCt diMeNSiONS Overall height of product 820-880 Overall width of product Overall depth of product Depth of chassis (to back of front panel) Maximum extension of drawer Depth of front panel Height of chassis Height of levelling feet 9-69 Height of drawer fronts Height of upper front panel... -
Page 7: Cabinetry Dimensions
CABiNetry diMeNSiONS Side Minimum clearances from adjacent cabinetry min. 13 mm clearance min. 2 mm from a corner clearance cupboard to adjacent cupboard door CABiNetry diMeNSiONS Inside height of cavity* min. 820 Inside width of cavity Inside depth of cavity min. -
Page 8: Cavity Preparation
CAVity PrePArAtiON ImpORTANT! the power outlet BeNCHtOP must be located in a cabinet adjacent to the dishwasher cavity. 220-240 VAC min. 9.5 A Moisture 10 mm protection water Connection tape must be applied. Recommended COLd (Maximum 60°C). 3/4“ BSP (GB20) to suit flat washer. - Page 9 MAXiMUM diStANCe Of HOSeS & COrd frOM CHASSiS edge Left HANd Side rigHt HANd Side Drain hoses - 2000 mm Drain hoses - 1800 mm Inlet hose - 1650 mm Inlet hose - 1250 mm Power cord (excl.plug) - 1650 mm Power cord (excl.plug) - 1650 mm...
- Page 10 NOW CHOOSE WHICH INSTALLATION mETHOD (A) OR (b) IS mORE SUITAbLE FOR YOUR CAbINETRY... reCOMMeNded MetHOd (A) - SeCUre witHOUt drAwer reMOVAL (frAMeLeSS CABiNetry ONLy) AttACH Side MOUNtiNg BrACKetS PULL tHrOUgH HOSeS & PUSH iNtO tHe CAVity Clip all four side mounting brackets optionally attach the When fitting brackets, two top mounting...
- Page 11 SeCUre tO tHe CABiNetry ON tHe SideS OPtiONALLy SeCUre tO tHe CABiNetry ABOVe The top mounting Open the brackets will only drawer halfway. (x2) bend upwards a Using a flat maximum of 10 mm. bladed Replace the grey screwdriver, rubber plug back into prise the grey the trim moulding rubber plug out...
- Page 12 ALterNAtiVe MetHOd (B) - SeCUre By drAwer reMOVAL PULL tHrOUgH HOSeS & PUSH iNtO tHe CAVity reMOVe tHe LOwer drAwer To prevent kinked hoses optionally attach the Either sit the drawer down on the left two top mounting When fitting brackets, hand side (recommended) or rotate the brackets ensure the ends are...
- Page 13 SeCUre tO tHe CABiNetry ON tHe SideS OPtiONALLy SeCUre tO tHe CABiNetry ABOVe The top mounting brackets will only (x2) bend upwards a maximum of 10 mm. For further adjustment, using the most appropriate length Hexagonal socket supplied, fully extend levelling feet up to required distance by hand.
- Page 14 fit tHe SUPPLied tOeKiCK PANeL Carefully bend and snap off. min.2 mm Once the sides are removed, score/cut all the clearance way down the middle of the toekick. HEIGHT OF TOEKICK min.12 mm clearance On a board, lay the toekick on Use a file to smooth the top edges.
- Page 15 tHere Are twO differeNt PLUMBiNg ANd drAiNAge OPtiONS. CHOOSe wHiCH iS MOre SUitABLe. dishwasher and Ø 38 mm Standpipe dishwasher using drain hose joiner onto sink trap/waste tee Supplied drain hose joiner to suit If space is limited If space is limited 19 mm waste tee for fixing, push for fixing, push...
- Page 16 CONNeCt iNLet HOSe tO COLd wAter PLUg PrOdUCt iN Tighten coupling with spanner. No leaks! Ensure the supplied rubber washer is fitted inside the coupling.
-
Page 17: Troubleshooting
trOUBLeSHOOtiNg Excessive water remaining above the filter plate, after the rinse cycle ● ● Check for a kinked drain hose, blocked waste connection, highloop not properly installed, drain hose not routed correctly or spray arms not in place. No water supply (This is displayed as a ‘A1’ fault) ●... -
Page 18: Final Checklist
fiNAL CHeCKLiSt tO Be COMPLeted By tHe iNStALLer Check all parts are installed. Turn on the power and water supplies, then open the drawers. You should hear a beep and see a program indicator light up on the control panel. Ensure that all panels and parts thereof are secure and final electrical tests have been conducted in accordance with local electrical regulations. - Page 20 www.fisherpaykel.com Copyright © Fisher & Paykel 2014. All rights reserved. The product specifications in this booklet apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time. You should therefore check with your Dealer to ensure this booklet correctly describes the product currently available.
