Product Overview; Product Description; Models And Characteristics; Preliminary Checks - Key Automation RAY2524 Instructions And Warnings For Installation And Use

EN

2 - PRODUCT OVERVIEW

2.1 - Description of the product
The RAY gear motors are destined to be installed in systems for the
automation of gates with hinged doors.
The RAY gear motors have been designed and constructed to be
fitted onto hinged doors within the weight limits indicated in the
2.2 - Model and technical characteristics
Code
RAY2524
RAY2524E
RAY4024
RAY4024E
RAY40
RAY40110
TECHNICAL DATA
MODELS
TECHNICAL SPECIFICATIONS
Speed
Thrust force
Working cycle
Opening time at 90°
Working stroke
Control board
Power supply
Absorption
Engine power
Capacitor
Thermoprotection
Integrated lights
Degree of protection
Dimensions (L - P - H)
Weight
Operating temperature
Leaves maximum weight

3 - PRELIMINARY CHECKS

Before installing this product, verify and check the following steps:
- Check that the gate or door are suitable for automation
- The weight and size of the gate or door must be within the maxi-
mum permissible operating limits specified in Fig. 2
- Check the presence and strength of the security mechanical stops
of the gate or door
- Check that the mounting area of the product is not subject to flood-
ing
- Conditions of high acidity or salinity or proximity to heat sources
could cause malfunction of the product
- Extreme weather conditions (for example the presence of snow,
ice, high temperature range, high temperatures) may increase the
friction and therefore the force required for the handling and initial
10
Description
Gear motor for hinged doors with max length 2.5 m and weight 250 Kg, 24 Vdc
Gear motor for hinged doors with max length 2.5 m and weight 250 Kg with encoder, 24 Vdc
Gear motor for hinged doors with max length 4 m and weight 300 Kg, 24 Vdc
Gear motor for hinged doors with max length 4 m and weight 300 Kg with encoder, 24 Vdc
Gear motor for hinged doors with max length 4 m and weight 300 Kg, 230 Vac
Gear motor for hinged doors with max length 4 m and weight 300 Kg, 110 Vac
RAY2524 RAY4024
RAY2524E RAY4024E
2,6 cm/s 1,5 cm/s
1500 N 2000 N
80%
adjustable adjustable
415 mm 415 mm
14AB 14AB2
24 Vdc 24 Vdc
3,5 A
85 W 120 W
-
-
yes
IP44
844-100-104 mm 844-100-104 mm
6 Kg
-20°+55°C -20°+55°C
500 Kg 600 Kg
technical specifications table.
The use of gear motors for applications which differ from those
indicated above is prohibited.
RAY40
1,6 cm/s
2000 N
80% 40%
25 sec
415 mm
CT202
230 Vac
5 A 1,2 A
280 W
- 8 µF
- 150 °C
yes -
IP44 IP44
844-100-104 mm
8 Kg 8 Kg
-20°+55°C
600 Kg
starting point may be higher than under normal conditions.
- Check that the manual operation of gate or door is smooth and
friction-free and there is no risk of derailment of the same
- Check that the gate or door are in equilibrium and stationary if left
in any position
- Check that the power line to supply the product is equipped with
proper grounding safety and protected by a magnetothermal and
differential security device
- Provide the power system with a disconnecting device with a gap
of contacts enabling full disconnection under the conditions dictated
by the overvoltage category III.
- Ensure that all materials used for the installation comply with cur-
rent regulations
RAY40110
1,6 cm/s
2000 N
40%
25 sec
415 mm
CT202V120
110 Vac
2,2 A
280 W
20 µF
150 °C
-
IP44
844-100-104 mm
8 Kg
-20°+55°C
600 Kg
