  • Page 2 • FT Universal Tire Balancer (#1498) • Wire Cutters • FT Dual Turnbuckle Wrench (#1114) • Green Slime shock lube (#1105) • Needle Nose Pliers Associated Electrics, Inc. Customer Service 21062 Bake Parkway. Tel: 949.544.7500 Lake Forest, CA 92630 Fax: 949.544.7501...
  • Page 3 :: Hardware - 1:1 Scale View :: Hardware - 1:1 Scale View :: Hardware - 1:1 Scale View :: Hardware - 1:1 Scale View Button Head (bhcs) Flat Head (fhcs) Ball Bearings 3x4mm (91158) 3x8mm (25201) 5x8x2.5mm (8680) 3x5mm (31530) 3x10mm (25202) 3x8mm (31532) 3x12mm (25203)
  • Page 4 :: Table of Contents :: Table of Contents 1....Cover 15....Rear End Build 2....Introduction 16....Rear Suspension Build 3....1:1 Hardware “Fold Out” 18....Center Diff Install 4....Table of Contents 19....Electronics Install 5....Safety Tips / Quick Start Guide 21....

  • Page 5: Battery Installation

    5/24 :: Safety Tips Safety Tips Your SR7 can hit some incredible speeds and has the potential to be very dangerous if not handled and cared for properly. Here are some general safety tips to keep in mind while operating your RC vehicle. •...
  • Page 6 :: Quick Start Guide - (cont.) Quick Start Guide - (cont.) Radio System Tuning and Controls: Radio System Tuning and Controls: RULE: Transmitter on First / Vehicle on Second, DO NOT hold the trigger when turning on the radio. Vehicle off First / Transmitter off Last! Refer to Radio owners manual for more in-depth Slide the battery cover to remove cover.
  • Page 7 :: Differentials (Front / Rear) - Differentials (Front / Rear) - Step 1 Step 1 25926 25926 Diff Shim Diff Shim 25926 25926 25926 25926 Sun Gear Sun Gear O-Ring O-Ring 25926 25926 25923 25924 Input Pin Input Pin Diff Case Ring Gear 25940 10x19x5mm...
  • Page 8 :: Differentials (Center) - Differentials (Center) - Step 4 Step 4 25203 3x12mm 25926 FHCS Planetary Gear Shim 25926 25926 Diff Cross Planetary 25926 Gear Diff Gasket 25926 Cross Pin Insert :: Shocks - Shocks - Step 1 Step 1 26044 25918 Shock Body...
  • Page 9 :: Shocks - Shocks - Step 3 Step 3 Install the shock spring Install the shock spring cup in between the cup in between the 25942 shock eyelet and the shock eyelet and the Spring up travel spacer. up travel spacer. Collar O-Ring 25942...
  • Page 10 :: Front End - Front End - Step 3 Step 3 8680 5x8x2.5mm FT Bearings 26007 Steering Bellcrank 26007 Steering Post 26005 26075 25211 Center FT Center 3x10mm Brace, Front Brace, Front, BHCS Carbon :: Front End - Front End - Step 4 Step 4 2308 3x18mm...
  • Page 11 :: Front End - Front End - Step 6 Step 6 26042 25215 26005 Pinion Gear, M3 Locknut, 26042 Center Black Brace, Rear Pinion Gear 26075 Input Spline FT Center Brace, Rear, Carbon 25201 25940 3x8mm 26002 10x19x5mm FHCS Center Bearing Bulkhead 89214...
  • Page 12 :: Front End - Front End - Step 9 Step 9 26010 Anti-Roll 26047 Bar Eyelet Anti-Roll Bar Pivot Ball 26047 91737 Roll Bar 3x20mm Ball, 4.8mm Setscrew 8691 2.5x12mm SHCS Install two. Build two. :: Front End - Front End - Step 10 26014 Shock 25225...
  • Page 13 :: Front Suspension - Front Suspension - Step 2 Step 2 25932 Wheel Hex 91564 8x16x5mm 25932 7732 Bearing Wheel Hex 4x4mm Setscrew Build two. :: Front Suspension - Front Suspension - Step 3 Step 3 26010 Upper Arm 26010 44mm Turnbuckle 25612...
  • Page 14 :: Front Suspension - Front Suspension - Step 5 Step 5 26011 25187 Body Support, 3x14mm Front BHCS 81261 26011 4x16mm Body Mount, BHCS Front 89209 81262 3x18mm 4x10mm FHCS FHCS :: Front Suspension - Front Suspension - Step 6 Step 6 89202 89206...
  • Page 15 :: Rear End - Rear End - Step 1 Step 1 26042 26042 25201 26035 Pinion Gear Pinion Gear, 3x8mm Arm Mount, Input Spline FHCS 26070 FT Arm Inserts, 26014 25201 Carbon Fiber Bearing 89208 3x8mm Support, 26001 FHCS 3x14mm Rear Suspension FHCS...
  • Page 16 :: Rear End - Rear End - Step 4 Step 4 26014 25225 Shock 3x3mm Tower Setscrew 89207 4x12mm 26008 BHCS Chassis Brace, Rear 26076 FT Chassis Brace, Rear, Carbon 26047 91158 Anti-Roll 3x4mm BHCS :: Rear End - Rear End - Step 5 Step 5 :: :: Rear Suspension - Rear Suspension - Step 1...
  • Page 17 :: Rear Suspension - Rear Suspension - Step 3 Step 3 26010 26010 Upper Arm 50mm Turnbuckle 26010 26010 Rod End Hub Spacer, 3.5mm 26010 6.8mm 25612 Pivot Ball Locknut, Long Neck M3 Flanged 31.00mm 26036 Hub Hinge Install two. Build two.
  • Page 18 :: Rear Suspension - Rear Suspension - Step 6 Step 6 :: :: Center Differential - Center Differential - Step 1 Step 1 26041 Motor Mount 81263 4x16mm 81262 FHCS 89214 4x10mm 4x12mm FHCS 81262 89209 FHCS 4x10mm 3x18mm FHCS FHCS :: Center Differential - Center Differential - Step 2...
  • Page 19 :: Electronics - Electronics - Step 1 Step 1 26002 89222 25211 Servo 2.5x8mm 26002 3x10mm Mount Box SHCS Receiver BHCS Box Cover Receiver 6727 Servo Tape 25202 3x10mm FHCS :: Electronics - Step 2 26010 25187 Pivot Ball 3x14mm 5.8mm BHCS 89245...
  • Page 20 :: Electronics Electronics - - Step 4 Step 4 26079 26041 SR7 FT Motor Motor Heat 81264 Mount Sink w/Fan Washer 4x20mm Unit FHCS 7732 4x4mm Set Screw 81261 4x16mm 26020 BHCS 14T Pinion :: Electronics Electronics - - Step 5 Step 5 26003 Battery Foam...
  • Page 21 :: Electronics Electronics - - Step 6 Step 6 25211 3x10mm BHCS Battery 26009 ESC Mount 25211 3x10mm BHCS 25202 3x10mm FHCS :: Wheel / Tire - Wheel / Tire - Step 1 Step 1 26017 Hoonicorn Tires and Wheels, Mounted 25932 Wheel Hex...
  • Page 22 :: Body - Body - Step 1 Step 1 26054 31530 26054 Hoonicorn 3x5mm 26054 Headlight Engine BHCS Headlight and Intake Back Cover 31532 3x8mm BHCS 26054 Hoonicorn Body 26054 Grill Mount 25211 89212 3x10mm 3x30mm 26054 BHCS FHCS Grill :: Body Body - - Step 2 Step 2...
  • Page 23 :: Body Body - - Step 3 Step 3 26054 25211 Bumper 3x10mm BHCS 26054 Wing 26054 Mount Bumper Mount 26054 Wing 26054 Rear Logo 26054 Rear Tail Light 25211 3x10mm BHCS :: Body Body - - Step 4 Step 4 2208 Large Body Clips...
  • Page 25 :: Tuning Tips :: Tuning Tips :: Bag 2 - Bag 2 - Step 1 Step 1 Tips for Beginners: Before making any changes to the standard setup, make sure you can get around without crashing. Changes to your vehicle will not be benefi cial if you can’t stay in control. Once you can get around consistently, start tuning your vehicle.
