IP Policy-ADSL PPPoE
1. Press
button to enter the
Function Select Mode.
2. Press
or
button
to scroll the main menu till it appears
Function Select - System Setting.
And then press
to enter the
option.
3. Press
or
button to
scroll the menu till it appears IP Addr.
Policy - ADSL PPPoE. And then
press
to enter the option.
4. PPPoE Login Name: Enter the
login name provided by your ISP.
5. PPPoE Password: Enter the
password provided by your ISP.
6. PPPoE Type: There are two types
you can select: Type 1 or Type 2.
Normally set to 1.
7. PPPoE Timeout: Set the PPPoE
timeout by minutes. "0" means always
on-line.
After finishing the setup, please jump to the section "Other
Common Setup" in this Chapter for further instructions.
BESTip ATA GSM User Manual
23
BESTip ATA GSM User Manual
Other Common Setup
After selecting and configuring the IP Policy, you
need to continue to set the following parameters.
Remember to press
button to effect the
setting and go to the next option.
1. Station ID: The default value is
1. The configuration is needed to be
changed only when you connect
more than one BESTip devices at
NAT router. You must set these
BSETip devices with different
Station ID.
2. Gatekeeper: There are four
options you can select:AUTO, Type
1, Type 2 and OFF. "Auto" is
applicable most of the time. Select
OFF only if your BESTip is
connected in a private network.
3. Country Code: Please key in
your country's telephone Country
Code. For example, "1" for USA,
"44" for U.K.
4. Area Code: Please key in your
state/city telephone Area Code.
5. IDD Prefix: Please key in the
International Direct Dial prefix code.
"00" in most cases.
24
