IP Policy－DHCP
DHCP: Dynamic Host Configuration Protocol is a method for
assigning IP address and other IP parameters to computers on
the IP network in a single message with great flexibility. IP
addresses can be static or temporary depending on the needs
of the network.
1. Press button to enter the
Function Select Mode.
2. Press or button to
scroll the main menu till it appears
Function Select - System Setting.
And then press to enter the
option.
3. Press or button to
scroll the menu till it appears IP
Policy - DHCP. Then press
to enter the option.
4. Press to go to the next
option, and you do not need to
configure the information.
Please jump to the section "Other Common Setup" in this
Chapter for further instructions.
BESTip ATA GSM User Manual
21
BESTip ATA GSM User Manual
IP Policy－Static IP
If you select Static IP mode, please consult your ISP or MIS to
have the information listed below. Please use the keypad on
your phone or the buttons on BESTip to input the information
obtained.
1. Press button to enter the
Function Select Mode.
2. Press or button to
scroll the main menu till it appears
Function Select - System Setting.
And then press to enter the
option.
3. Press or button to
scroll the menu till it appears IP
Policy – STATIC IP. And then
press to enter the option.
4. My IP Address: The unique LAN
IP address assigned to the BSETip.
5. NETMASK Address: Please enter
netmask, normally it is
255.255.255.xxx.
6. Router Address: The IP address
of the router/gateway device that
connects your BESTip to the Internet.
7. Primary DNS : Enter the IP
address of the Domain Name Server.
8. Secondary DNS: Secondary DNS
is optional. You may leave it blank.
Afeter finishing the setup, please jump to the section "Other
Common Setup" in this Chapter for further instructions.
