Page 1: User Manual
Thank you for purchasing our product. Please read this User’s Manual before using the product. Change without notice 20” TFT LCD MONITOR USER MANUAL... -
Page 3: Warning
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH VENTILATION GRILLS. CAUTION: CAUTION Explanation of Graphical Symbols The lightning flash with arrowhead symbol, within an equilateral triangle, is intended.to alert the user to the presence of uninsulated "dangerous voltage"... -
Page 4: Important Information
Important Information IMPORTANT SAFEGUARDS 1. READ INSTRUCTIONS All the safety and operating instructions should be read before the unit is operated. 2. RETAIN INSTRUCTIONS The safety and operating instructions should be retained for future reference. 3. HEED WARNINGS All warnings on the unit and in the operating instructions should be adhered to. 4. -
Page 5: Safety Precautions
Safety Precautions Federal Communications Commission (FCC) Statement This Equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 6: Table Of Contents
Table of Contents Warning…………………………………………………………………………………………………… 3 Important Information…………………………………………………………………………………… 4 Safety Precautions……………………………………………………………………………………….. 5 Table of Contents………………………………………………………………………………………… 6 Components………………………………………………………….. …………………………………. 6 Feature……………………………………………………………………………………………………. 7 Exploring Your New Monitor…………………………………………………………………………….. 8 Backside Connections…….………………………………………………………………………….…. 9 Selecting a Location for the Monitor…………………………………………………………………… 9 Connecting your Monitor………………………………………………………………………………… 10 Connecting Device………………………………………………………………………………………. 11 Setup your Monitor………………………………………………………………………………………..12 Video Setup………………………………………………………………………………………….……... -
Page 7: Feature
Feature ■Professional TFT LCD for surveillance in 20.1” with multiple connection. ■Compatible with VGA(640X480), SVGA(800X600), XGA(1024X768), SXGA(1280X1024), UXGA (1600 x 1200) resolution. ■Picture-In-Picture feature that allow multi-picture display ■High brightness level and contrast ration with super wide viewing angle ■Built-in 3D comb filter and 3D de-interlace for crispy picture performance ■Fast response time and refresh rate without time lagging. -
Page 8: Exploring Your New Monitor
Exploring Your New Monitor You can operate your monitor by using the buttons on the front panel. The side panels provide the inputs to connect other equipment to your monitor. Front Panel Back Side... -
Page 9: Backside Connections
Backside Connections 1, 2 AUDIO 2 IN (R, L) Stereo Audio Signal Input, this input is for AV2 (Refer to Note below) ( R) ( R) 3, 4 AUDIO 2 OUT (R, L) ( L) ( L) Audio looping outputs for AUDIO 2 ( R) ( R) 5, 6... -
Page 10: Connecting Your Monitor
Connecting your Monitor If you don’t have experience in electronic equipment connection before, you may wish to read this section. (Cables are not supplied, just for reference) l Audio cables are usually color coded according to use: red and white for audio. The red audio cable is for the stereo right channel, and the white audio cable is for the stereo left (or mono) channel. -
Page 11: Connecting Device
Connecting Device Connect PC to Monitor through VGA connector as shown on the above picture Connect External device such as DVD or Game Player to Monitor as shown on the above picture Connect CCD Camera 1 and 2 to Monitor through Video Input 1 and 2 (BNC Connector) as showing on the above picture Support Resolution 20.1”... -
Page 12: Setup Your Monitor
Setup your Monitor SOURCE: Select input signal from AV1, AV2, S-Video, DVI or VGA. MENU: OSD menu ON / OFF control. (EXIT Item) ITEM: Auto-optimize displaying picture under PC mode. Enter: This “ Select” Button can be either “Enter” function in OSD Menu) ADJUST: Increase or decrease the value on OSD menu. -
Page 13: Video Setup
Video Setting Brightness: Adjusts the overall picture shade and brightness. Contrast: Permits adjustment of contrast between light and dark areas of the picture. Saturation: Adjusts the intensity of the color. Hue: To determine the lightness and colorfulness of the picture. Sharpness: Sets the desired sharpening enhancement to the picture. -
Page 14: Vga Setup
VGA Setting Brightness: Adjusts the overall picture shade and brightness. Contrast: Permits adjustment of contrast between light and dark areas of the picture. Auto Adjustment: Picture adjustment automatic correction, like clock and phase. Image H Position: Allows adjustment for horizontal position. Image V Position: Allows adjustment for vertical position. -
Page 15: Audio Setup
Audio Setting Volume: Controls built-in speakers’ output volumes. Bass: Adjusts the tone to low frequency part of the sound. Treble: Adjust the high or acute of the sound. Balance: Adjusts the softness of loudness of notes in the sound. Mute: To disable the audio function. -
Page 16: Pip Setup
PIP Setting PIP Mode: This function allows the PIP mode to be selected. PIP Source: This function allows the source of the PIP to be selected. PIP Swap: This function allows the position of PIP to be exchanged. POP Zoom: Only Operate under POP (Side By Side) mode. -
Page 17: System Setting
System Setting ack Mount Aspect Ratio: To change the display mode. Auto Source Detection: The monitor will auto detect the video source when power ON. Color Temperature: Selects color temperature of either 6500°K or 9300°K. Key Lock: The Key-Lock function is provided to prevent tempering. To unlock, press ITEM and MENU. -
Page 18: Information
Information ack Mount Resolution: To show the resolution. H Frequency: To show the horizontal frequency. V Frequency: To show the vertical frequency. -
Page 19: Dvi Setting
DVI Setting Brightness: Adjusts the overall picture shade and brightness. Contrast: Permits adjustment of contrast between light and dark areas of the picture. Default:... -
Page 20: Lcd Monitor Mounting Guide
LCD monitor Mounting Guide ack Mount Desktop Arm Mount (VESA Standard) When adjusting the VESA Standard Arms to the back side of the LCD monitor, please use the 4x8(mm) screw. For further information’s please refer to the Arm Manual. Be sure fixed and locked in the maximum position. Mounting the monitor on the rack Note: When adjusting to a rack, you will need to use an optional rack mount to the back side of the LCD... -
Page 21: Troubleshooting
Troubleshooting Before calling a service technician, please check the following table for a possible cause of the problem and some solution. Symptom Solution Monitor will not turn on ● Make sure the power cord is plugged in, then press POWER button. No picture, no sound ●... -
Page 22: Lcd Color Monitor Specifications
LCD Color Monitor Specification Model Number 20” Front Control Source / Menu / Item / Adjust 640 x 480 @ 60/72/75 800 x 600 @ 56/60/72/75 Resolution / Scan 1024 x 768 @ 60/70/75 1280 x 1024 @ 60/75 1600 x 1200 @ 60 Active Area (mm) 408(H) x 306(V)mm LCE Panel Type... -
Page 23: Lcd Color Monitor Dimensions
LCD Color Monitor Dimensions... - Page 24 85-ML2011-A003G A...
