Hi Sharp HS-ML1002 User Manual

10.4" tft lcd monitor

Advertisement

Quick Links

Thank you for purchasing our product.
Please read this User's Manual before
using the
product.
Change without notice
10.4" T F T L C D M O N I T O R
U S E R M A N U A L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HS-ML1002 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hi Sharp HS-ML1002

  • Page 1 Thank you for purchasing our product. Please read this User’s Manual before using the product. Change without notice 10.4” T F T L C D M O N I T O R U S E R M A N U A L...
  • Page 2: Warning

    WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH VENTILATION GRILLS. CAUTION: CAUTION Explanation of Graphical Symbols The lightning flash with arrowhead symbol, within an equilateral triangle, is intended.to alert the user to the presence of uninsulated "dangerous voltage"...
  • Page 3: Important Information

    Important Information IMPORTANT SAFEGUARDS 1. READ INSTRUCTIONS All the safety and operating instructions should be read before the unit is operated. 2. RETAIN INSTRUCTIONS The safety and operating instructions should be retained for future reference. 3. HEED WARNINGS All warnings on the unit and in the operating instructions should be adhered to. 4.
  • Page 4: Safety Precautions

    Safety Precautions Federal Communications Commission (FCC) Statement This Equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 5: Table Of Contents

    Table of Contents Warning……………………………………………………………………………………………………. 2 Important Information……………………………………………………………………………………. 3 Safety Precautions……………………………………………………………………………………….. 4 Table of Contents………………………………………………………………………………………… 5 Components………………………………………………………….. …………………………………. 5 Feature……………………………………………………………………………………………………. 6 Exploring Your New Monitor…………………………………………………………………………….. 7 Backside Connections…….………………………………………………………………………….…. 8 Selecting a Location for the Monitor…………………………………………………………………… 8 Connecting your Monitor………………………………………………………………………………… 9 Connecting Devices……………………………………………………………………………………… 10 Setup your Monitor……………………………………………………………………..………………...
  • Page 6: Feature

    Features ■ Professional TFT LCD for surveillance in 10.4” with multiple connections ■ Compatible with VGA (640X480) ■ Picture-In-Picture feature that allow multi-picture display ■ High brightness level and contrast ratio with super wide viewing angle ■ Built-in 3D comb filter and 3D de-interlace for display picture performance ■...
  • Page 7: Exploring Your New Monitor

    Exploring Your New Monitor You can operate your monitor by using the buttons on the front panel. The side panels provide the inputs to connect other equipment to your monitor. Front Panel 10.4’’ Back Side...
  • Page 8: Backside Connections

    Backside Connections 1, 2 AUDIO 2 IN (R, L) Stereo Audio Signal Input, this input is for AV2 (Refer to Note below) 3, 4 AUDIO 2 OUT (R, L) Audio looping outputs for AUDIO 2 5, 6 AUDIO 1 IN (R, L) Stereo Audio Signal Input, this input is for AV1 or S-Video (Refer to Note below) 7, 8...
  • Page 9: Connecting Your Monitor

    Connecting your Monitor If you don’t have experience in electronic equipment connection before, you may wish to read this section. (Cables are not supplied, just for reference) Audio cables are usually color coded according to use: red and white for audio. The red audio cable is for the stereo right channel, and the white audio cable is for the stereo left (or mono) channel.
  • Page 10: Connecting Devices

    Connecting Devices Connect PC to Monitor through VGA connector as shown on the above picture Connect External device such as DVD or Game Player to Monitor as shown on the above picture Connect CCD Camera 1 and 2 to Monitor through Video Input 1 and 2 (BNC Connector) as showing on the above picture Support Resolution 10.4”...
  • Page 11: Setup Your Monitor

    Setup your Monitor Auto-optimize displaying picture under PC mode. AUTO: This “ Auto” Button can be either “Enter” function in OSD Menu) Enter: CCD Mode: Under AV/1 / AV2 / S-Video press Auto can be changed to CCD/Video mode toggle. OSD menu ON / OFF control.
  • Page 12: General Setup

    General Setup The monitor will auto detect the video source when power ON. Auto Source Detect : Multi-Language selection in English. OSD Language : This function is to assign a specific video signal when power ON. Power ON Control : The Key-Lock function is provided to prevent tempering.
  • Page 13: Video Setup

    Video Setup Adjusts the overall picture shade and brightness. Brightness : Permits adjustment of contrast between light and dark areas of the Contrast : picture. Adds coloring to the black and white picture content (of a color Color : signal), and is usually set for viewer’s preference in color saturation. Adjusts all the colors on the screen, but is most noticeable to the eye TINT : in reds and yellows, and is also usually set for pleasing face tones.
  • Page 14: Vga Setup

    VGA Setup A uto B rig h tne ss C o ntr ast C o lor Temp er at u re 9 300 H -p os iti on V - Pos iti on C lo ck P ha se D e fau lt Auto detect screen detail data such as clock and phase.
  • Page 15: Audio Setup

    Audio Setup Volume : Controls built-in speakers’ output volumes To disable the audio function. To enable, press MUTE again. Mute Sets AUDIO settings to the original factory setting. Default :...
  • Page 16: Pip Setup

    PIP Setup This function allow the PIP mode to be selected. Multi-Mode : The function allow the PIP Sub source to be selected. Sub Source : The selection of PIP window size. Sub Window Size: Sub Window H-Position : Control the PIP window position in horizontal position. Sub Window V-Position : Control the PIP window position in vertical position.
  • Page 17: Lcd Monitor Mounting Guide

    LCD monitor Mounting Guide Desktop Adjust the viewing angle of LCD in order to fit most comfortable monitoring status. Arm Mount (VESA Standard) When adjusting the VESA Standard Arms to the back side of the LCD monitor, please use the M4x8mm (L) screw. For further information’s, please refer to the Arm Manual.
  • Page 18: Troubleshooting

    Troubleshooting Before calling a service technician, please check the following table for a possible cause of the problem and some solution. Symptom Solution Monitor will not turn on ● Makes sure the power cord is plugged in, then press POWER button. No picture, no sound ●...
  • Page 19: Specifications

    Specification Panel Size 10.4” Aspect Ratio Resolution / Scan 640 x 480 @ 60 Brightness 350cd/m (*1) Contract Ratio 300:1 (*1) Viewing Angle(H/V) Left 70°/ Right 70° / Up 40° / Down 70° CR>10 Response Time 60ms Sync. Format NTSC / PAL Frequency (Horizontal) PC: 31.5K Frequency (Vertical)
  • Page 20: Dimensions

    Dimensions 10.4”...
