- Page 1 Thank you for purchasing our product. Please read this User’s Manual before using the product. Change without notice 17” / 19” TFT LCD MONITOR Metal front with metal case USER’S MANUAL...
-
Page 2: Warning
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH VENTILATION GRILLS. CAUTION: CAUTION Explanation of Graphical Symbols The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage"... -
Page 3: Important Information
Important Information IMPORTANT SAFEGUARDS 1. READ INSTRUCTIONS All the safety and operating instructions should be read before the unit is operated. 2. RETAIN INSTRUCTIONS The safety and operating instructions should be retained for future reference. 3. HEED WARNINGS All warnings on the unit and in the operating instructions should be adhered to. 4. -
Page 4: Table Of Contents
Table of Contents Warning…………………………………………………………………………………………………… 2 Important Information…………………………………………………………………………………… 3 Table of Contents………………………………………………………………………………………… 4 Components………………………………………………………….. …………………………………. 4 Feature……………………………………………………………………………………………………. 5 Backside Connections…….………………………………………………………………………….…. 6 Connecting your Monitor………………………………………………………………………………… 7 Connecting Device………………………………………………………………………………………. 8 Setup your Monitor……………………………………………………………………..………………... 9 Video Setup………………………………………………………………………………………….…… 10 VGA Setup………………………………………………………………………………………………… 11 Audio Setup………………………………………………………………………………………………. 12 PIP Setup……………………………………………………………………………………………….…... -
Page 5: Feature
Feature ■Professional TFT LCD for surveillance in 17”/19” with multiple connection. ■Compatible with VGA(640X480), SVGA(800X600), XGA(1024X768), SXGA(1280X1024) resolution. ■Picture-In-Picture feature that allow multi-picture display ■High brightness level and contrast ration with super wide viewing angle ■Built-in 3D comb filter and 3D de-interlace for crispy picture performance ■Fast response time and refresh rate without time lagging. -
Page 6: Backside Connections
Backside Connections 1.3. AUDIO 2 IN (R, L) Stereo Audio Signal Input, this input is for AV2 (Refer to Note below) 2.4. AUDIO 2 OUT (R, L) Audio looping outputs for AUDIO 2 5.7. AUDIO 1 IN (R, L) Stereo Audio Signal Input, this input is for AV1 or S-Video (Refer to Note below) 6.8. -
Page 7: Connecting Your Monitor
Connecting your Monitor If you don’t have experience in electronic equipment connection before, you may wish to read this section. (Cables are not supplied, just for reference) l Audio cables are usually color coded according to use: red and white for audio. The red audio cable is for the stereo right channel, and the white audio cable is for the stereo left (or mono) channel. -
Page 8: Connecting Device
Connecting Device Connect PC to Monitor through VGA connector as shown on the above picture Connect External device such as DVD or Game Player to Monitor as shown on the above picture Support Resolution 17” / 19” Monitor Display modes Mode Resolution Refresh rate 640 x 480 up to 75Hz SVGA... -
Page 9: Setup Your Monitor
Setup your Monitor ENTER: Enter to item setup MENU: OSD menu ON / OFF control. (EXIT Item) DOWN: Menu item select direction button down Menu item select direction button up SOURCE: Select input signal from Camera, AV1, AV2, S-Video, DVI, VGA. POWER: Monitor power ON / OFF. -
Page 10: Video Setup
Video Setting Brightness: Adjusts the overall picture shade and brightness. Contrast: Permits adjustment of contrast between light and dark areas of the picture. Saturation: Adjusts the intensity of the color. Hue: To determine the lightness and colorfulness of the picture. Sharpness: Sets the desired sharpening enhancement to the picture. -
Page 11: Vga Setup
VGA Setting Brightness: Adjusts the overall picture shade and brightness. Contrast: Permits adjustment of contrast between light and dark areas of the picture. Auto Adjustment: Picture adjustment automatic correction, like clock and phase. Image H Position: Allows adjustment for horizontal position. Image V Position: Allows adjustment for vertical position. -
Page 12: Audio Setup
Audio Setting Volume: Controls built-in speakers’ output volumes. Bass: Adjusts the tone to low frequency part of the sound. Treble: Adjust the high or acute of the sound. Balance: Adjusts the softness of loudness of notes in the sound. Mute: To disable the audio function. -
Page 13: Pip Setup
PIP Setting PIP Mode: This function allows the PIP mode to be selected. PIP Source: This function allows the source of the PIP to be selected. PIP Swap: This function allows the position of PIP to be exchanged. POP Zoom: Only Operate under POP (Side By Side) mode. -
Page 14: System Setup
System Setting ack Mount Aspect Ratio: To change the display mode. Auto Source Detection: The monitor will auto detect the video source when power ON. Color Temperature: Selects color temperature of either 6500°K or 9300°K. Key Lock: The Key-Lock function is provided to prevent tempering. To unlock, press AUTO and MENU. -
Page 15: Information
Information ack Mount Resolution: To show the resolution. H Frequency: To show the horizontal frequency. V Frequency: To show the vertical frequency. -
Page 16: Dvi Setup
DVI Setting Brightness: Adjusts the overall picture shade and brightness. Contrast: Permits adjustment of contrast between light and dark areas of the picture. Default: Back to original factory setting. -
Page 17: Troubleshooting
Troubleshooting Before calling a service technician, please check the following table for a possible cause of the problem and some solution. Symptom Solution Monitor will not turn on ● Make sure the power cord is plugged in, then press POWER button. No picture, no sound ●... -
Page 18: Lcd Color Monitor Specifications
LCD Color Monitor Specification Panel Size 17.0” 19.0” Aspect Ratio 640 x 480 @ 60/72/75 640 x 480 @ 60/72/75 800 x 600 @ 56/60/72/75 800 x 600 @ 56/60/72/75 Resolution / Scan 1024 x 768@ 60/70/75 1024 x 768 @ 60/70/75 1280 x 1024 @ 60/70/75 1280 x 1024 @ 60/70/75 Brightness... -
Page 19: Lcd Color Monitor Dimensions
LCD Color Monitor Dimensions... - Page 20 85-ML1752-A002G-A...
